GEARBOX COUNTERSHAFT

GEAR SHIFTING MECHANISM FOR KTM DUKE 2017

GEAR SHIFT LEVER

Item numbers

SHIFT FORK F. SLIDINGGEAR 5 12

75034002100

$56,09

Unit Price

SHIFT FORK F. SLIDINGG. 3/4 12

75034001100

$54,37

Unit Price

SHIFT FORK F. SLIDINGGEAR 6 12

75034003100

$56,09

Unit Price

NEEDLE ROLLER DIN5402 6X14, 8

0402061480

$5,80

Unit Price

SHIFT FORK SHAFT

75034019000

75034019100

$18,34

Unit Price

SHIFT SHAFT ASSY

75034005133

$118,52

Unit Price

TENSIONING SPRING 0, 8MM

56534013100

$1,44

Unit Price

SPRING GUIDE

54634020000

$9,10

Unit Price

RETURN SPRING 2, 2MM '95

54634014100

$9,36

Unit Price

STOP DISK 14X30X1, 5 STEEL

75034050000

$5,80

Unit Price

NEEDLE SLEEVE HK 1412 14X20X12

54632095000

$9,89

Unit Price

SHAFT SEAL RING 14X24X6B VITON

0760142461

$9,36

Unit Price

HH COLLAR SCREW M6X20 TX30

0024060206

$4,34

Unit Price

LOCKING LEVER CPL. 07

75034024044

$27,05

Unit Price

SLEEVE FOR LOCKING LEVER 07

75034052000

$5,80

Unit Price

ARRESTING LEVER SPRING 03

60034023000

$2,89

Unit Price

AH SCREW DIN6912 M6X30 8.8

0012060303

$1,44

Unit Price

SHIFT DRUM LOCATING CPL. 07 (0912060309S, 60034023000, 61434024000, 76834115001, 76834215000)
SHIFT DRUM LOCATING CPL. 07

75034015000

$158,64

Unit Price

BALL BEARING 61805 C3

0625618050

$62,03

Unit Price

SHIFTING DRUM CPL.

76634012044

76634012144

$181,09

Unit Price

NEEDLE BEAR HK3512 35X42X12

0618354212

$13,98

Unit Price

MAGNET BRACKET CMPL.
MAGNET HOLDER CPL.

79234012020

$82,88

Unit Price

SPRING F. SHIFTING SHAFT CPL.

75034007044

$12,40

Unit Price

FLAT HEAD SCREW ISO7380 M5X8 A2 TX25

073800501002

0738050082

$1,44

Unit Price

GEAR POSITION SENSOR

60411023000

$245,11

Unit Price

CYL. SCREW DIN6912 M5X14 8.8

0984050143S

$2,89

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
