HANDLEBAR / CONTROLS

FRAME FOR KTM FREERIDE 2015

ENGINE GUARD

Item numbers

FRAME ORANGE ''700L1''

7000300100004

$1 576,46

Unit Price

CONNECTION SUPPORT RIGHT

70003001152

72103001152

$420,67

Unit Price

LINKAGE BRACKET, LEFT PREMOUNT.

70003101051

72103101051

$466,08

Unit Price

SUBFRAME CPL.

70003002033

$403,25

Unit Price

CLOSING COVER SWINGARM SM 03

58404041000

$9,89

Unit Price

AH SCREW DIN912 M8X12

0912080123

$1,44

Unit Price

ENGINE BRACKET SCREW 85 SX

47003013000

$11,87

Unit Price

AH-COLLAR SCREW M10X20 ISA45

0035100209

$11,08

Unit Price

CROSS PIPE

70003001060

$30,74

Unit Price

ENGINE GUARD CPL.

70003090144

$234,82

Unit Price

FOOTREST MOUNTING R/S '12

70003039100

$64,01

Unit Price

FOOTREST MOUNTING L/S '12

70003038100

$55,43

Unit Price

AH-COLLAR SCREW M10X35 ISA45

0032100356S

$5,80

Unit Price

THREADED BUSH M12 D20

50180105

$21,90

Unit Price

HH COLLAR SCREW M10X56 WS13 08

69004094000

$7,38

Unit Price

AH-COLLAR SCREW M8X50 ISA45

0035080506S

$7,38

Unit Price

SIDE STAND SPRING PLATE 12

70003024050

$20,71

Unit Price

SCREW FOR PLASTIC K60X20 SW6

0017060205

$2,89

Unit Price

PLASTIC SCREW K7X25 PT1447

0016070253

$4,34

Unit Price

SEAT LOCKING MECHANISM

70007039000

$21,77

Unit Price

MONOSHOCK SCREW TOP M12X80

70004016000

$41,57

Unit Price

BRACKET QUICK LOCK

70007039050

$46,06

Unit Price

HH COLLAR SCREW M6X10 TX30

0024060106

$4,34

Unit Price

SPROCKET COVER

70003096000

70003096100

$27,58

Unit Price

COLLAR BUSHING 6, 3X8X13X9, 5

45239060050

$7,38

Unit Price

CHAIN SLIDING PIECE BELOW CPL.

70003053000

$7,38

Unit Price

HH COLLAR SCREW M8X35 TX40

0025080356

$5,80

Unit Price

FOOTREST CPL. 14

47103040033

$155,48

Unit Price

FOOTREST R/S

47103041000

$60,31

Unit Price

FOOTREST L/S

47103040000

$61,90

Unit Price

PIN FOR FOOT PED 51.5X9.8 MM

54803044000

$17,54

Unit Price

FOOTREST SPRING L/S & R/S

54603041000

$7,38

Unit Price

WASHER DIN 125 A 10.5

0125100003

$2,89

Unit Price

PIN DIN 0094-3.2X25 NIRO

0094032253

0094032250

$1,44

Unit Price

RIVET NUT M10

69004095000

69004095100

$7,38

Unit Price

CHAIN SLIDING KIT BELOW

70003053010

$12,92

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FRAME of your KTM FREERIDE E-XC of 2015. Let us know if you have any questions.
