GEARBOX COUNTERSHAFT

GEAR SHIFTING MECHANISM FOR KTM SUPERMOTO 2013

WATERPUMP

Item numbers

SHIFT FORK 1-4 GEAR

60034001100

$77,87

Unit Price

SHIFT FORK 2-3 GEAR

60034002100

$86,18

Unit Price

SHIFT FORK 5-6 GEAR

60034003100

$67,39

Unit Price

SHIFTING ROLLER 6X8X5, 2

50334018100

$5,80

Unit Price

SHIFT RAIL 11, 8X105MM

59034020000

$18,86

Unit Price

SHIFT RAIL 11, 8X89MM

59034019000

$18,07

Unit Price

PRESSURE SPRING 0, 9MM

58038023200

$5,80

Unit Price

SHIFT SHAFT CPL.

60034005133

$108,76

Unit Price

TENSIONING SPRING 0, 8MM

56534013100

$1,44

Unit Price

SPRING GUIDE

54634020000

$9,10

Unit Price

RETURN SPRING 2, 2MM '95

54634014100

$9,36

Unit Price

STOP DISK 14X30X1

54634050000

$2,89

Unit Price

SHIFT ROLLER CPL. 06

60034012300

$164,29

Unit Price

CONTACT SPRING 03

60034014000

$1,44

Unit Price

CONTACT BOLT 03

60034037000

$5,80

Unit Price

SHIFT ARRESTING CPL. 03

60034015044

$59,78

Unit Price

AH SCREW DIN0912-M 6X30

0912060303

$2,89

Unit Price

LOCKING LEVER CPL.

60034024144

$63,22

Unit Price

HH COLLAR SCREW M5X20 TX30

0025050206

$2,89

Unit Price

WASHER DIN7349-5X15X2

0349000050

$1,44

Unit Price

SLEEVE FOR LOCKING LEVER

54634052300

$4,34

Unit Price

ARRESTING LEVER SPRING 03

60034023000

$2,89

Unit Price

NEEDLE SLEEVE HK 1412 14X20X12

54632095000

$9,89

Unit Price

RADIAL SHAFT SEAL 14X24X6 B

0760142460

$13,06

Unit Price

GEAR-POSITION SENSOR 06

60011023100

$65,99

Unit Price

O-RING 27, 5X2, 5 NBR

0770275025

$1,44

Unit Price

AH SCREW DIN0912-M 5X12

0912050123

$2,89

Unit Price

BALL BEARING 61805 C3

0625618050

$62,03

Unit Price

GROOVED BALL BEARING 6808 JRC3

0625068080

$45,40

Unit Price

SHIFT LEVER CPL. 07

6003403104401S

$183,73

Unit Price

STEEL WASHER 6, 4X17X3

50232050001

$7,38

Unit Price

PAIR OF WASHERS M 6 NORDLOCK

50233041000

$5,80

Unit Price

SPECIAL SCREW M6X19 WS=8 10.9

59009062019

$2,89

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the GEAR SHIFTING MECHANISM of your KTM 990 SUPERMOTO R ABS of 2013. Let us know if you have any questions.
