OIL PUMP

IGNITION SYSTEM FOR KTM SUPERDUKE 2009

ELECTRIC STARTER MOTOR

Item numbers

PULSE GENERATOR LC8 04

60039034100

$96,88

Unit Price

HH COLLAR SCREW M6X16 TX30

0025060166

$4,34

Unit Price

COIL SPROKET 22Z O. CYL. PIN

61039020000

$4,67

Unit Price

STICK COIL 03

60039006000

$133,84

Unit Price

SPARK PLUG KR8DI

61139093000

$32,06

Unit Price

IGNITION ROTOR 04

60039005100

$1 155,78

Unit Price

WASHER 17X32X4 03

60039040010

$7,38

Unit Price

AH EXPAND. SCREW M16X1, 5 05

60039003100

$10,94

Unit Price

HH COLLAR SCREW M6X35 TX30

0025060356

$4,34

Unit Price

STATOR 03

60039004000

$355,19

Unit Price

DOWEL 9, 8 X7X10

49030090000

49030090100

$2,89

Unit Price

IGNIT.COVER GASK.MATRI.CS0, 5MM

60030040100

$44,87

Unit Price

IGNITION COVER CPL. 06

60030002144

6003000214423

$283,39

Unit Price

O-RING 24.00X2.50 VITON

0770024025

07700240251

$4,34

Unit Price

SCREW PLUG M24X1, 5 PA 6.6

6003009400023

$4,34

Unit Price

CU-SEAL RING DIN7603-6X10X1

0603061001

$2,89

Unit Price

VENTILATION CONNECTOR M16X1, 5

60030022000

$11,74

Unit Price

HH COLLAR SCREW M6X30 TX30

0025060306

$4,34

Unit Price

CLAMP STD DN22

00049220121

$2,89

Unit Price

VARIABLE ONE-EAR CLAMP 22, 6MM

00050226706

$4,34

Unit Price

WASHER DIN0125-A 6, 4

0125060003

$1,44

Unit Price

GENERATOR LINE BRACKET

60039040020

$4,34

Unit Price

BACK-PRESSURE VALVE CPL. (00050226706, 60030090300)
BACK-PRESSURE VALVE CPL.

60030090344

$48,30

Unit Price

ENGINE BREATHER HOSE BOTTOM

60030087101

Contact

ENGINE BREATHER HOSE TOP

60030087102

Contact

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
