Displacement

Year

Model

Finish line

Parts catalogue

Parts diagram

HANDLEBAR / CONTROLS

FRAME FOR KTM DUKE 2022

REAR SUB FRAME

Item numbers

FRAME 636 TA

63603001200EB

$1 469,94

Unit Price

FRAME TRIM, RIGHT

63603082000

$29,99

Unit Price

CLIP NUT M5

69008021080

$4,34

Unit Price

SPECIAL SCREW M5X12

69008021160

$5,80

Unit Price

CLIP NUT M6

54603048100

$5,80

Unit Price

DAMP. COMPONENT ABS MODUL

62142041000

$5,80

Unit Price

RANGE CHANGE METAL NUT M5

54603048200

$7,38

Unit Price

TANK SUPPORT

50307014100

$7,38

Unit Price

HEX COLLAR SCREW M6X12 ISA30 SELF-LOCKIN
HEX COLLAR SCREW M6X12 ISA30 S

0025060126S

$1,44

Unit Price

ENGINE STRUT BLACK

6410301300033

$133,84

Unit Price

CAP HEAD BOLD M8X50 ISR 45
CYL. SCREW DIN14579 M8X50 SS

014579080506S

$7,38

Unit Price

AH-COLLAR SCREW M10X60 ISA45

0035100609S

$13,19

Unit Price

BRACKET ABS LINE DIA7.5

64142046000

$2,89

Unit Price

QUICK RELEASE RUBBER GROMMET

47106003160

$5,80

Unit Price

ISA SCREW, M10X65 ISA45

0035100656S

$9,89

Unit Price

SELF LOCKING NUT M10 CU WS=14

54310086100

$2,89

Unit Price

CABLE GUIDANCE LEFT

64103034000

$7,38

Unit Price

FASTENING PLUGS M8

64103034120

$14,11

Unit Price

CABLE GUIDANCE RIGHT

64103035000

$5,80

Unit Price

SILENTBLOC 20X15-M6X10-(1)

43205062100

$19,66

Unit Price

ISA COLLAR SCREW M10X40 ISA45

0035100409S

$8,96

Unit Price

ISA SCREW M10X45 ISA45

0035100456S

$8,04

Unit Price

FRONT FOOTPEG BRACKET RIGHT BLACK
FRONT FOOTPEG BRACKET RIGHT BL

63603039000C1

$203,40

Unit Price

FRONT FOOTPEG BRACKET LEFT BLACK
FRONT FOOTPEG BRACKET LEFT BLA

63603038000C1

$201,16

Unit Price

FOOTREST FRONT R/S CPL. 05

61003051000

$69,55

Unit Price

FOOTREST FRONT L/S CPL. 05

61003050000

$70,87

Unit Price

FOOTREST BOLT, REAR

60003044100

$11,34

Unit Price

RETAINING WASHER DIN 6799 - 6

0799060003

$1,44

Unit Price

RETURN SPRING FOOTREST

76003042000

$4,34

Unit Price

ISA COLLAR SCREW M10X80 ISA45

0035100809S

$4,34

Unit Price

DISTANCE PIECE

6410303900133

$17,94

Unit Price

HH COLLAR SCREW M5X10 TX30

0025050106

$1,44

Unit Price

ROLLER

6410303800133

$9,49

Unit Price

SPROCKET COVER

64103096000

$34,70

Unit Price

CABLE HOLDER, ATTACHABLE

64111059020

$4,34

Unit Price

FRAME LOCKING CAP

64103088000

$2,89

Unit Price

SET PROTECTION STICKER FRAME

64103092044

$18,86

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FRAME of your KTM 890 DUKE R of 2022. Let us know if you have any questions.

Select your KTM DUKE model from 2022
