HANDLEBAR / CONTROLS

FRAME FOR KTM SX 2015

SHOCK ABSORBER

Item numbers

FRAME ''471M3'' ANTHR.-MET.

47103001000BE

$1 654,12

Unit Price

SUB FRAME

47103002000

$431,36

Unit Price

HEXAGON NUT DIN934 M8
HEXAGON NUT DIN0934-M 8

0934080003

$2,89

Unit Price

PLUG 37MM

54606004000

$2,89

Unit Price

SELF LOCKING NUT M8 10.9

54310086200

$4,34

Unit Price

REINFORCING

47103013100

$10,68

Unit Price

HH COLLAR SCREW M8X35 TX40

0025080356

$5,80

Unit Price

SUB FRAME APPLICATION LEFT

78103002010

$31,67

Unit Price

SUB FRAME APPLICATION RIGHT

78103002020

$28,76

Unit Price

SPECIAL SCREW M8X26 WS=10

59001037000

$4,34

Unit Price

SELF LOCKING NUT M10 CU WS=14

54310086100

$2,89

Unit Price

FLAT HEAD SCREW M. ISA45 M8X20

0019080206S

$2,89

Unit Price

ENGINE BRACKET SCREW 85 SX

47003013000

$11,87

Unit Price

CABLE SUPPORT KHS NR.150-47610

58111076000

$5,80

Unit Price

FOOTREST CPL. 14

47103040033

$155,48

Unit Price

FOOTREST L/S

47103040000

$61,90

Unit Price

FOOTREST R/S

47103041000

$60,31

Unit Price

FOOTREST SPRING L/S & R/S

54603041000

$7,38

Unit Price

PIN FOR FOOT PED 51.5X9.8 MM

54803044000

$17,54

Unit Price

WASHER DIN 125 A 10.5

0125100003

$2,89

Unit Price

PIN DIN 0094-3.2X25 NIRO

0094032253

0094032250

$1,44

Unit Price

CHAIN SLIDING PIECE BELOW '97

51103053000

$12,92

Unit Price

LOCK WASHER 8MM

36003014000

$2,89

Unit Price

HH COLLAR SCREW M8X30

0025080306

$4,34

Unit Price

BUSHING 8, 2X10X20

51103053051

$5,80

Unit Price

ADH. FOIL TRANSP. 80X80 MM 04

50307012000

$2,89

Unit Price

CHAIN SLIDING KIT BELOW MINI

51103053110

$27,58

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FRAME of your KTM 85 SX 17/14 of 2015. Let us know if you have any questions.
