FRONT FORK / TRIPLE CLAMP

FRONT FORK (PARTS) FOR KTM SX 2013

HANDLEBAR / CONTROLS

Item numbers

SCREW CAP M46X1, 5 CPL.

43570395S1

$508,32

Unit Price

O-RING 40X2 NBR70 BLACK

46811042

$2,89

Unit Price

ADJUSTING KNOB + SCREW

48600812S

48600812ST

$7,38

Unit Price

CROSS COUNTERSUNK HEAD SCREW M4X8
CROSS COUNTERSUNK HEAD SCREW M

48600481

$2,89

Unit Price

O-RING 3X1, 5 NBR70

48600046

$1,44

Unit Price

FORK OUTER TUBE 44, 14X510 DT49 DB53 NATU (43570099, 43570982)
FORK OUTER TUBE 44, 14X510 DT49

43570614E

$357,16

Unit Price

ROUND-WIRE SNAP RING 53X2

43570099

$37,34

Unit Price

GUIDE BUSHING 43X47X12
GUIDE BUSHING 42X44X20

43570618

$16,49

Unit Price

SUPPORTWASHER 45X52, 5X1, 5

43570092

$28,37

Unit Price

SHAFT SEAL SKF 43X52, 9X11, 4 BLACK

43570201

43570623

$23,48

Unit Price

SNAP RING SB53X1, 5 ACC DRAWING

43570008

$4,34

Unit Price

DIRT SCARPER SKF 43MM BLACK

43570202

43570624

$23,62

Unit Price

GUIDE BUSHING 42X44X20

43570617

$16,09

Unit Price

STOP 12, 4X28, 6X135 CPL.

43570396S

$64,67

Unit Price

ADJUSTMENT TUBE 6X442

48600695

$27,71

Unit Price

PISTON ROD 12X476

48600694

$238,88

Unit Price

NEEDLE 4, 5X43, 6

48600277

$7,78

Unit Price

O-RING 2X1, 5 NBR70

48600298

$1,44

Unit Price

SPRING (5, 4) 4-23 REBOUND

48600444

$4,34

Unit Price

PRELOAD BUSH 26, 5X38X2, 5

43570133

$4,34

Unit Price

PRELOAD BUSH 26, 5X38X2, 5

43570133

$4,34

Unit Price

PRELOAD BUSH 26X35X4

43570134

$4,34

Unit Price

PRELOAD BUSH 26X38X10

43570135

$5,80

Unit Price

PRELOAD BUSH 26, 5X38X1, 5

43570136

$4,34

Unit Price

SPRING 3, 2 N/MM SET D=4, 2MM

95010031S

$184,79

Unit Price

SPRING 3, 4 N/MM SET D=4, 4MM

95010032S

$184,79

Unit Price

SPRING 3, 6 N/MM SET

95010033S

$184,79

Unit Price

SPRING RETAINER 33, 5X38, 2X3

43570131

$25,46

Unit Price

GUIDE BUSHING 12X14X10

48600430

$9,10

Unit Price

SCREW SLEEVE M27X0, 8 CPL.

48600830S2

$51,07

Unit Price

O-RING 6X1, 2 NBR70

48600299

$1,44

Unit Price

SPRING (13, 9) 17-32 REBOUND CPL.

48600511

48600511S

$3,95

Unit Price

TAP REBOUND 07

48600513

$22,56

Unit Price

SPRING RETAINER 12, 3X19X1, 25 REBOUND
SPRING RETAINER 12, 3X19X1, 25 R

48600525

$2,89

Unit Price

SPRING (11, 4) 0, 4-8 VALVE

48600382

$2,89

Unit Price

PISTON RING 21X23X5

48600455

48601625

$6,35

Unit Price

PISTON 6, 07X22, 7X13

48600575

$20,84

Unit Price

NUT M6X0, 5 H6, 5 WAF10 REBOUND

40540486

$5,80

Unit Price

TUBE 23X330

48600870

$103,21

Unit Price

ADAPTER 23X28X70

48600764

$31,54

Unit Price

O-RING 41X2 NBR70 SILICONIZED YELLOW
O-RING 41X2 NBR70 SILICONIZED

43570023

$19,13

Unit Price

AXLE CLAMP L/S + TUBE CPL.

43570559S1

$555,18

Unit Price

AXLE CLAMP R/S + TUBE CPL.

43570558S1

$875,81

Unit Price

NUT VALVE M6X0, 5 H6, 5 WAF17

48600885

$7,38

Unit Price

SPRING (8, 5) L6, 5 VALVE

48600202

$2,89

Unit Price

COMPRESSION, CMPL.

48600586S

48600586S3

$53,18

Unit Price

PISTON 6X27, 8X9 COMPRESSION

48600047

$13,85

Unit Price

O-RING 21X2 NBR70

46811499

$1,44

Unit Price

O-RING 24X2 NBR70

35480320

$1,44

Unit Price

O-RING 8X2 NBR70

48600049

$1,44

Unit Price

COPPER DISC 29, 5X33, 5X1

48600004

$5,80

Unit Price

RUBBER CAP 35X10 NBR80

48600141

$5,80

Unit Price

FUCHS GREASE IPR (250G)

T511

T14034

$48,83

Unit Price

FORK FLUID VISCOSITY 4.0 5L
FORK OIL SAE4 5L

48601166S1

$211,19

Unit Price

REPAIR KIT

R511

R511T

$195,48

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FRONT FORK (PARTS) of your KTM 85 SX 17/14 of 2013. Let us know if you have any questions.
