SHOCK ABSORBER

SHOCK ABSORBER (PARTS) FOR KTM SX 2011

EXHAUST

Item numbers

SHOCK ABSORBER TOP H40 135DEG.

46180348

Contact

DCC-COMPR.DAMP.CONTROL CPL. 07

50180213S10

$156,11

Unit Price

DISTANCE BUSH 12X15/18/24, 5X10, 5
DISTANCE BUSH 12X15/18/24, 5X10

46180007

$25,07

Unit Price

SEAL RING 19, 5X26X3

46180003

$7,91

Unit Price

ROUND-WIRE SNAP RING 25X1

50180168

$1,44

Unit Price

BALL JOINT BEARING 15X25X13

50180005

$41,44

Unit Price

HS CYLINDER-HEAD SCREW R1/8 L8

50180095

$3,42

Unit Price

STICKER WP CLEAR 35X55

52000014

Contact

RESERVOIR 52X100 M54X1 BLACK

50180522

Contact

O-RING 41X5 VITON75

46180014

$2,89

Unit Price

PISTON 52MM RESERVOIR

46180002

$61,63

Unit Price

PISTONRING 47, 5X50, 5X3, 9

46180015

$14,11

Unit Price

O-RING 5, 28X1, 78 HNBR70 RED

46810893

S208600003000FB

$0,91

Unit Price

PLUG SCREW M5X6 CPL.

36120151

36120151ST

$5,80

Unit Price

RUBBER CAP DO NOT OPEN 22X5, 5 NBR
RUBBER CAP DO NOT OPEN 22X5, 5

46811208

$4,34

Unit Price

O-RING 48X2 NBR70 SILICONIZED

46810016

$1,44

Unit Price

SLEEVE D=48

46180340

Contact

LOCK WASHER M52X1, 5

46180352

Contact

TUBE M52X1, 5

46180345

Contact

SPRING RETAINER M52X1, 5

46180353

Contact

AH SCREW DIN0912-M 5X25

0912050253

$1,44

Unit Price

MAINSPRING (59) 45-215 DAMPER WHITE
MAINSPRING (59) 45-215 DAMPER

91010201

$184,79

Unit Price

SPRING 215 30 N/MM D=9, 00 ORAN

91010272

$193,67

Unit Price

MAINSPRING (59) 35-215 DAMPER ORANGE
MAINSPRING (59) 35-215 DAMPER

91010273

$213,04

Unit Price

SPRING 215 40 N/MM D=9, 50 ORG

91010274S

$193,67

Unit Price

SPRING RETAINER 28X56X15

46180349

$43,55

Unit Price

PISTON ROD NUT M10X1

46180356

$10,94

Unit Price

O-RING 37X, 82X1, 78 VITON70 GREEN
O-RING 37X, 82X1, 78 VITON70 GRE

46810035

$2,89

Unit Price

PISTON RING 43, 95X45, 95X8

46811206

$25,07

Unit Price

PISTON 10, 05X35, 5X13, 7 3, 5/5, 5

14460016

$82,09

Unit Price

SEPARATION BUSH 17X12X18

46180339

Contact

REBOUND DISC H=0

46180179

Contact

REBOUND DISC 12X34X7 H4

46180337

$46,19

Unit Price

PISTON 5X4, 5X/6X6

46180441

Contact

TAP PISTON ROD D=13, 5

46180343

Contact

SPINDEL D=18 LC=159 CPL.

46180342S

Contact

O-RING 5X1, 5 VITON70

50180397

Contact

NEEDLE REBOUND L=169

46180346

Contact

O-RING NBR 7, 5X2

46180018

$2,39

Unit Price

NEEDLE GUIDE

46180350

Contact

SEAL SUPPORT 46X28 CMPL.

46180669S

S614620000S0000

$99,59

Unit Price

SCREW CAP M16X1

46180355

Contact

O-RING 12X1 NBR70

46180013

$2,89

Unit Price

O-RING 4X1, 5 NBR70

50180222

$1,44

Unit Price

SPRING (1, 7) L7, 9

48600028

$4,34

Unit Price

STEEL BALL D3

40540603

$1,44

Unit Price

ADJUSTMENT SCREW SLOT REBOUND

46180006

$31,80

Unit Price

ADJUSTMENT SCREW SLOT REBOUND

46180016

$55,19

Unit Price

WASHER 58, 6X73, 6X1, 5

50180410

$5,80

Unit Price

ROUND-WIRE SNAP RING 49X1, 5
ROUND-WIRE SNAP RING 49X1, 8

46810010

$4,34

Unit Price

COVER 46, 12X6, 2 H15, 7

46180338

$48,70

Unit Price

RUBBER PAD 17, 2X45, 2X40 BLACK

50180276

$11,87

Unit Price

HH LOCKING NUT M18X1 H5 WAF24

50180283

Contact

SHOCK ABSORBER BOT. KGW L=54, 5

46180347

Contact

SHOCK ABSORBER FLUID 5 LT

50180342S1

50180751S1

$211,19

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the SHOCK ABSORBER (PARTS) of your KTM 85 SX 17/14 of 2011. Let us know if you have any questions.
