CYLINDER

CRANKSHAFT / PISTON FOR KTM SX 2009

REED VALVE CASE

Item numbers

PISTON CPL. 47MM SIZE 1 2005

47030007100I

$179,78

Unit Price

PISTON CPL. 47MM SIZE 2 2005

47030007100II

$179,78

Unit Price

CON. ROD. REP. KIT 85 SX '06

47030015100

Contact

SPACER SLEEVE 85 SX 2003

47030016000

$40,64

Unit Price

O-RING 18, 77X1, 78 NBR 70

0770020180

$1,44

Unit Price

CRANKSHAFT CPL.

47030018100

47030118100

$669,89

Unit Price

LOCKING RING VSK 12

50230029012

$2,89

Unit Price

COLLAR NUT, M12X1, RIGHT

49030021000

49030021100

$2,89

Unit Price

HH SCREW W. COLLAR M10X1, 25X20

47032019000

$26,12

Unit Price

PISTON RING 85 SX 2003

47030030000

$57,41

Unit Price

WIRE LOCK RING 85 SX 2003

47030074000

$2,89

Unit Price

PISTON PIN

47030033000

47230033000

$23,62

Unit Price

NEEDLE BEARING KBK 14X18X17 03

47030034000

$47,51

Unit Price

WOODRUFF KEY DIN 6888 4X5X13

0888040050

$5,80

Unit Price

WOODRUFF KEY DIN6888-3X5X13

0888030050

$2,89

Unit Price

SEAL SHAFT RING 20X35X6 BTSL

47030076100

$30,35

Unit Price

OIL SEAL

0760304261

$23,22

Unit Price

CYLINDRICAL ROLLER BEARING NJ205

47030082000

49030023000

$105,06

Unit Price

BALL BEARING 22X52X15

47030083000

$40,51

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
