FRONT BRAKE MASTER CYLINDER

REAR BRAKE MASTER CYLINDER FOR KTM SX 2006

FRONT BRAKE CALIPER

Item numbers

HH COLLAR SCREW M5X12 TX30

0015050123

0025050126

$4,34

Unit Price

HH COLLAR SCREW M6X20 TX30

0015060203

0025060206

$4,34

Unit Price

HH COLLAR SCREW M6X12 TX30

0015060123

0025060126

$4,34

Unit Price

DEEP GROOVE BALL BEARING SKF 6000-2RS1
DEEP GROOVE BALL BEARING SKF 6

0625060002

$17,41

Unit Price

SPECIAL SCREW M8X26 WS=10

59001037000

$4,34

Unit Price

HEX NUT DIN 934 M6

0934060003

$1,44

Unit Price

FLANGED NUT M8 WS10

46030045000

$11,08

Unit Price

COLLAR NUT M10-SW13 ZNNI

54630044000

55530044000

$1,44

Unit Price

AH-COLLAR SCREW M10X40 ISA45

0912100406

0032100406S

$5,80

Unit Price

FOOT BRAKE LEVER CPL. 85 SX 03

47013050044

$169,87

Unit Price

STEP PLATE FOR BRAKE LEVER

54813051000

$15,56

Unit Price

RETURN SPRING FOR BRAKE LEVER

54603062000

54603062200

$9,23

Unit Price

JOINT HEAD CMP6

54813055000

54813055100

$28,10

Unit Price

PRESSURE ROD 85 SX 06

47013056100

$18,47

Unit Price

FOOT BRAKE CYL. REAR CPL. D=12

47013060200

4701306030001S

$267,02

Unit Price

REP. SET PISTON REAR D=11 2003

47013061000

$59,52

Unit Price

REP. SET PISTON REAR D=12 2004

47013061100

$106,51

Unit Price

CYLINDER COVER REAR 85 SX 03

47013062000

$12,53

Unit Price

GASKET CYLINDER COVER REAR 03

47013063000

$15,17

Unit Price

HOLLOW SCREW BRAKE CYLINDER 03

47013025000

$15,30

Unit Price

AH.SCREW DIN0912-M 4X10

0912040103

$2,89

Unit Price

BRAKE HOSE REAR 85 SX 03

47013070000

$130,27

Unit Price

O-RING 8, 00X1, 00 FORMULA

0770080019

$2,89

Unit Price

BRAKE FLUID DOT 4.0

306054

Contact

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the REAR BRAKE MASTER CYLINDER of your KTM 85 SX 19/16 of 2006. Let us know if you have any questions.
