GEARBOX COUNTERSHAFT

GEAR SHIFTING MECHANISM FOR KTM ADVENTURE 2020

WATERPUMP

Item numbers

HH COLLAR SCREW M6X15 TX30

0024060156S

$2,89

Unit Price

SHIFT LOCKER CPL.

63534015000

$61,76

Unit Price

DEEP GROOVE BALL BEARING 6807

0625068070

$37,74

Unit Price

INT. TORX FLAT HEAD M5X12 T25

0019050121S

$2,89

Unit Price

BEARING RETAINING BRACKET

63534011100

63534011200

$2,89

Unit Price

SHIFT DRUM 6G

63534012001

$134,89

Unit Price

GROOVED BALL BEARING 42/30 C3

0625068060

0410003000700

$29,03

Unit Price

MAGNET BRACKET CMPL.
MAGNET HOLDER CPL.

79234012020

$82,88

Unit Price

GEAR POSITION SENSOR

79211023000

$171,32

Unit Price

HH COLLAR SCREW M5X12 TX30

0025050126

$4,34

Unit Price

HH COLLAR SCREW M6X16 TX30 SL

0025060166S

$2,89

Unit Price

BEARING RETAINING PLATE

63533022000

$5,80

Unit Price

SHIFT SHAFT CPL.

63534005033

$94,24

Unit Price

TENSIONING SPRING 0, 8MM

56534013100

$1,44

Unit Price

SPRING GUIDE

54634020000

$9,10

Unit Price

RETURNSPRING 2MM

61234014000

$9,10

Unit Price

STOP DISK 14X30X1

54634050000

$2,89

Unit Price

NEEDLE SLEEVE HK 1412 14X20X12

54632095000

$9,89

Unit Price

RADIAL SHAFT SEAL 14X24X6 B

0760142460

$13,06

Unit Price

DOWEL PIN DIN 7 A1 2.5M6X24

0007025241

$1,44

Unit Price

MAGNET HOLDER

63534050000

$69,95

Unit Price

VALVE SPRING

63534050010

0740001502500

$4,34

Unit Price

THRUST WASHER DIN 988 14X20X0.5
THRUST WASHER DIN 988 14X20X0.

0988142005

$1,44

Unit Price

RETAINING RING DIN 471 14X1

0471140100

$1,44

Unit Price

PULL ROD

6413403000033

$60,18

Unit Price

PAIR OF WASHERS M 6 NORDLOCK

50233041000

$5,80

Unit Price

SHIFT ASSISTANT SENSOR

63534051000

$219,64

Unit Price

HH COLLAR SCREW M5X16 ISA30 SS

0025050166S

$1,44

Unit Price

DETENT ARM CPL.

63534024000

$45,92

Unit Price

STEP WASHER

63534052000

$2,89

Unit Price

DETENT ARM SPRING

63534023000

$1,44

Unit Price

SHIFT FORK 5-6 GEAR

63534002000

$20,71

Unit Price

SHIFT FORK

63534001100

$24,67

Unit Price

SHIFT FORK SHAFT

75034019100

$18,34

Unit Price

NEEDLE ROLLER D8X20

0402080200

$2,89

Unit Price

SHIFT ROD CMPL.

63534036044

$82,36

Unit Price

OVAL HEAD SCREW ISR M6X20-A2-70-MK
OVAL HEAD SCREW ISR M6X20-A2-7

0738060205S

$1,44

Unit Price

SCREW ISO 14579-M8X30-10.9-MK BLACK
SCREW ISO 14579-M8X30-10.9-MK

014579080301S

$2,89

Unit Price

SELF LOCKING NUT M8 10.9

54310086200

$4,34

Unit Price

GEAR SHIFT LEVER PREASSEMBLED BLACK
GEAR SHIFT LEVER PREASSEMBLED

6353403104433

$171,85

Unit Price

SHIFTING LEVER SPRING 250

54634032100

$4,34

Unit Price

BOLT 6X25 FOR SHIFT LEVER

54634031050

$11,08

Unit Price

GROOVED BALL BEARING 608 2RS C3
GROOVED BALL BEAR. 608 2RS C3

0625006087

$30,22

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the GEAR SHIFTING MECHANISM of your KTM 790 ADVENTURE R of 2020. Let us know if you have any questions.
