REAR WHEEL

WIRING HARNESS FOR KTM ADVENTURE 2020

BATTERY

Item numbers

MAIN WIRING HARNESS

63511075000

$1 246,07

Unit Price

FRONT WIRING HARNESS

63511078000

63511078100

$299,10

Unit Price

ENGINE WIRING HARNESS

63511085000

$93,44

Unit Price

COVER FLAP, STARTER RELAY

64111058010

64111058110

$4,34

Unit Price

STARTER RELAY
STARTER RELAY 07

76211058000

$111,79

Unit Price

RUBBER CABLE TIE 45MM 03

60011093045

$4,34

Unit Price

RUBBER CABLE TIE 75MM 03

60011093075

$7,38

Unit Price

BAR SPACER 4/7 BLACK

60111094100

$8,17

Unit Price

RELAY CM1A-R-12V-H80 07

61111057000

$23,75

Unit Price

CABLE TIE 140/2, 5MM BLACK

44011076140

$1,44

Unit Price

CABLE TIE 200/4.6MM BLACK
CABLE TIE 200/3, 6MM BLACK

44011076200

$1,44

Unit Price

CABLE TIE 300/4, 8MM BLACK

44011076305

$2,89

Unit Price

PLUG-IN FUSE, BIG 30A
FUSE 30 A

58011109130

$2,89

Unit Price

TEMPERATUR SENSOR
TEMPERATURE SENSOR

61111018100

$44,60

Unit Price

CABLE HOLDER, ATTACHABLE

64111059020

$4,34

Unit Price

DC HORN 12V

76011060100

$29,16

Unit Price

CONNECTOR SUPPORT FRONT

63511048000

63511048100

$7,38

Unit Price

HH COLLAR SCREW M6X20 TX30

0024060206

$4,34

Unit Price

VOLTAGE REGULATOR

60311034000

$250,66

Unit Price

OVAL HEAD SCREW M5X14 TX25
SCREW M5X14 TORX 25 07

58605083014

$4,34

Unit Price

FLASHER UNIT

76511030000

$32,72

Unit Price

POWER SOCKET 12V

60711042000

$78,79

Unit Price

LID 12V-SOCKET

60311042050

$10,42

Unit Price

INTER. WIRING HARNESS, TURN SIGNAL RELAY
INTER. WIRING HARNESS, TURN SI

63511080000

$15,70

Unit Price

DIODE S3H-15 97

58411096100

$13,85

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the WIRING HARNESS of your KTM 790 ADVENTURE R RALLY of 2020. Let us know if you have any questions.
