FRONT FORK / TRIPLE CLAMP

FRONT FORK (PARTS) FOR KTM SMC 2022

HANDLEBAR / CONTROLS

Item numbers

FORK PROTECTION RING 59, 8MM

48601948

S639200001000FA

$2,89

Unit Price

STROKE INDICATOR 48MM RED

48602007

$5,80

Unit Price

AXLE CLAMP L/S WITH TUBE CPL.

48601318S1

$821,56

Unit Price

AXLE CLAMP R/S WITH TUBE CPL.

48601317S1

$784,20

Unit Price

SEAL KIT 48MM SKF BLACK

RP10012

RP10048T

$94,24

Unit Price

SCREW CAP M51X1, 5 REBOUND CPL.

48602039S

$87,90

Unit Price

SCREW CAP M51X1, 5 COMPRESSION CPL.
SCREW CAP M51X1, 5 COMPRESSION

48602040S

$87,90

Unit Price

O-RING 46X2 NBR70 SILICONIZED YELLOW
O-RING 46X2 NBR70 SILICONIZED

48600048

$4,34

Unit Price

WASHER 35X43X2, 5 PLASTIC

48600456

$2,89

Unit Price

PRELOAD BUSH 35X43X3, 5

48600457

$2,89

Unit Price

WASHER 35X43X1, 5 PLASTIC

48600458

$2,89

Unit Price

FORK OUTER TUBE 49.13X530 DT54 DB60

48601981

48602185

$313,88

Unit Price

GUIDE BUSHING SET FORK 48MM

R14047

R14047T

$36,29

Unit Price

ADJUSTER KIT SCREW CAP

RP10021

RP10021T

$8,04

Unit Price

HH COLLAR SCREW M8X35 TX40

0025080356

$5,80

Unit Price

CARTRIDGE RIGHT KTM 690 SM

48601067S1

$744,60

Unit Price

CARTRIDGE LEFT KTM 690 SMC

48601067S2

$744,60

Unit Price

SPRING C=5, 3 L=450 D=5, 5

91410043S

$205,91

Unit Price

AH SCREW M10X20 SET

00501020S1

00501020S1T

$4,61

Unit Price

STICKER SET, APEX PRO OC 90X40

52000210SET

52000209SET

$65,99

Unit Price

WASHER 32X42X2, 5 PLASTIC

48600113

$15,70

Unit Price

FORK FLUID VISCOSITY 4.0 5L

48601166S1

$211,19

Unit Price

FUCHS GREASE IPR (250G)

T14034

$48,83

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FRONT FORK (PARTS) of your KTM 690 SMC R of 2022. Let us know if you have any questions.
