SYSTÈME D'AIR SECONDAIRE

CLUTCH FOR KTM ENDURO 2020

GEARBOX MAIN SHAFT

Item numbers

CYL.SCREW DIN14580 M5X30

014580050306

$2,89

Unit Price

ANTICENTRIFUGAL RING

76632006000

$10,68

Unit Price

CLUTCH SPRING 3, 0X33, 5

58532080000

58532080001

$12,53

Unit Price

PRESSURE PLATE

76632003044

$68,89

Unit Price

HEX NUT M20X1, . H=6MM

60036073150

Contact

LOCK WASHER

75032018100

$5,80

Unit Price

MOVABLE HUB

76632002002

76632002102

$164,06

Unit Price

CLUTCH RELEASE SPRING

75032033000

$10,94

Unit Price

FIXED HUB

76632002001

76632002101

$183,60

Unit Price

STEPPED WASHER 07

75032009000

$13,19

Unit Price

HALF-WASHER 07

75032007000

$15,70

Unit Price

CLUTCH HOUSING CPL.

75032001144

75032001244

$753,44

Unit Price

OIL PUMP DRIVE WHEEL 07

75032050001

$5,80

Unit Price

NEEDLE BEARING K26X30X22ZW.KSE

56532095000

$33,65

Unit Price

WASHER 26X40X2 07

75032017000

$8,96

Unit Price

DEEP GROOVE BALL BEARING 6001.2RSR C3
DEEP GROOVE BALL BEARING 6001.

0625060016

Contact

PRESSURE BOLT 08

75032055100

$13,98

Unit Price

PUSH ROD 08

75032054200

$21,11

Unit Price

GASKET F. OUTPUT CYLINDER

59032065100

$7,91

Unit Price

O-RING 30X1.5 NBR 70
O-RING 30, 00X1, 50 NBR 70

0770300015

$2,89

Unit Price

PISTONKIT OUTPUT ZYL. DOT 27MM

26632066000

$125,39

Unit Price

O-RING 23, 52X1, 78 EPDM

26632067000

$5,80

Unit Price

OUTPUT CYL. DOT CPL. 27MM

79432061144

76132061044

$268,61

Unit Price

COUPLING LINE

76032063000

A63432063000

$97,80

Unit Price

HH COLLAR SCREW M6X20 TX30

0025060206

$4,34

Unit Price

HH COLLAR SCREW M6X35 TX30

0025060356

$4,34

Unit Price

STEEL DISK 1, 5 MM LC4 ?07
STEEL DISK 1, 5 MM LC4 ´07

75032112000

$25,99

Unit Price

LINING DISK 2, 7MM FCC 02

58332011300

76632011000

$29,03

Unit Price

RONDELLA ANTIVIBRAZIONE SET

58632016000

$87,90

Unit Price

LINING DISC CUT OUT

75032111100

76632010000

$33,12

Unit Price

STEEL DISK 1, 5MM NITRIDED

75032112100

$32,46

Unit Price

HOLDING SCREW GMB-M5X35

75032032000

$10,81

Unit Price

BLEEDER SCREW WITH CAP

54732064000

$31,01

Unit Price

CLUTCH DISK KIT WITHOUT SPRINGS

75032011110

76632010033

$309,13

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CLUTCH of your KTM 690 ENDURO R of 2020. Let us know if you have any questions.
