BRAKE ANTIBLOCK SYSTEM ABS FOR KTM DUKE 2016

WP SHIMS FOR SETTING

Item numbers

ABS-MODULE FILLED

76042131044

$5 128,98

Unit Price

ABS MOUNTING CPL.

76042040100

$101,89

Unit Price

BRAKE PIPE GUIDE

76042001150

$8,83

Unit Price

SILENTBLOC 20X15-M6X10-(1)

43205062100

$19,66

Unit Price

HH COLLAR SCREW M5X10 TX30

0025050106

$1,44

Unit Price

BANJO BOLT M10X1X19.5

62113020100

$12,40

Unit Price

SEALING RING DIN 7603 10X14X1

0603100141

$2,89

Unit Price

BRAKE LIGHT SWITCH REAR

62111051000

$41,04

Unit Price

ABS RELAY BRACKET

76042080050

$7,38

Unit Price

BRAKE PIPE

76042001000

$170,66

Unit Price

BRAKE PIPE

76042002000

$59,12

Unit Price

BRAKE HOSE

76042003100

$62,29

Unit Price

BRAKE PIPE

76042004100

$170,53

Unit Price

BLEEDER SCREW CPL. 05

62513020000

$38,80

Unit Price

ABS-SENSOR

76042125000

$268,21

Unit Price

PHONIC WHEEL, FRONT
SENSORGEAR FRONT

76042020000

$48,83

Unit Price

SENSOR WHEEL REAR
SENSORGEAR REAR

76042021000

$49,75

Unit Price

SPECIAL SCREW M8X25 SL TX40
SPECIAL SCREW M8X25 SS TX40

76009062000

$2,89

Unit Price

CLAMPING BRAKE PIPE

76001071100

$5,80

Unit Price

CLAMPING BRAKE PIPE

76001070100

$4,34

Unit Price

SELF LOCKING NUT DIN 985 M5
SELF LOCKING NUT DIN0985-M 5

0985050003

$2,89

Unit Price

HH COLLAR SCREW M5X20 TX30

0025050206

$2,89

Unit Price

CABLE SUPPORT 10/4MM 2014

54813026100

$2,89

Unit Price

BAR SPACER 4/7 BLACK

60111094100

$8,17

Unit Price

CABLE TIE 200/4.6MM BLACK
CABLE TIE 200/3, 6MM BLACK

44011076200

$1,44

Unit Price

CABLE TIE 300/4, 8MM BLACK

44011076305

$2,89

Unit Price

HH COLLAR SCREW M6X10 TX30

0025060106

$4,34

Unit Price

HH COLLAR SCREW M6X13 TX30

0024060136

$4,34

Unit Price

CAP HEAD BOLD ISO 14580 M6X16
SHCS ISO 14580 M6X16

014580060166

$2,89

Unit Price

GROUND CABLE LC4 ABS

76011097050

$5,80

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
