HANDLEBAR / CONTROLS

FRAME FOR KTM DUKE 2012

SIDE / MAIN STAND

Item numbers

FRAME ''760LA0'' ORANGE

7600300100004

$2 510,28

Unit Price

CONNECTION BRACKET ENG. L/S 07

7500300104901

$64,40

Unit Price

CONNECTION BRACKET ENG. R/S 07

7500310104901

$58,60

Unit Price

CAP HEAD BOLD M8X50 ISR 45
CYL. SCREW DIN14579 M8X50 SS

014579080506S

$7,38

Unit Price

SPECIAL SCREW M10X129 HEX8 08

75603015000

$11,08

Unit Price

SPECIAL SCREW M10X152 ISK8 07

75003014000

$9,49

Unit Price

COLLAR NUT M10-SW13 ZNNI

54630044000

55530044000

$1,44

Unit Price

CHAIN SLIDING PIECE 03

54804067000

$7,38

Unit Price

BUSHING 8, 2X10X20

51103053051

$5,80

Unit Price

HH COLLAR SCREW M8X30 TX40

0025080306S

$4,34

Unit Price

WASHER DIN 125 A -8.4

0125080003

$1,44

Unit Price

TAILBOOM L/S

7600300200192

$463,57

Unit Price

TAILBOOM R/S

7600300200292

$452,75

Unit Price

BRACE SUBFRAME

76003002010

$38,80

Unit Price

AH-COLLAR SCREW M8X25 ISA45

0035080256

$5,80

Unit Price

AH-COLLAR SCREW M8X40 ISA45

0035080406

$7,38

Unit Price

AH COLLAR SCREW M10X30 ISA45
SHCS M10X30 TX45

0035100309S

$4,34

Unit Price

FOOTREST BRACKET REAR L/S

7600304800001S

$115,88

Unit Price

FOOTREST BRACKET REAR R/S

7600304900001S

$122,09

Unit Price

AH-COLLAR SCREW M8X30 ISA45

0035080306S

$4,34

Unit Price

AH-COLLAR SCREW M8X50 ISA45

0035080506S

$7,38

Unit Price

BRACKET F. SILENCER

7600508400001S

$79,85

Unit Price

SHCS M8X20 TX45

0035080206S

$7,51

Unit Price

FOOTREST CPL. L/S REAR 03

60003050000

$86,71

Unit Price

FOOTREST CMPL. R/S REAR 03
FOOTREST CPL. R/S REAR 03

60003051000

$87,37

Unit Price

BOLT FOR FOOTREST REAR 03

60003044000

$12,53

Unit Price

RETAINING WASHER DIN 6799 - 6

0799060003

$1,44

Unit Price

ENGAGE PANEL FOOTREST R/S 03

60003052000

$7,38

Unit Price

ENGAGE PANEL FOOTREST L/S 03

60003152000

$7,38

Unit Price

FOOTRESTS CPL.

76003040033

$185,71

Unit Price

FOOTREST FRONT L/S CPL. 05

61003050000

$70,87

Unit Price

FOOTREST FRONT R/S CPL. 05

61003051000

$69,55

Unit Price

RETURN SPRING FOOTREST

76003042000

$4,34

Unit Price

FOOTREST SUPPORT

76003101095

$50,15

Unit Price

CHAIN SLIDING KIT UPPER CPL.

54804067010

$29,29

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
