HANDLEBAR / CONTROLS

FRAME FOR KTM DUKE 2011

SIDE / MAIN STAND

Item numbers

FRAME ''EH08'' BLACK MATT 08

7500300120033

Contact

CONNECTION BRACKET ENG. L/S 07

7500300104901

$64,40

Unit Price

CONNECTION BRACKET ENG. R/S 07

7500310104901

$58,60

Unit Price

CAP HEAD BOLD M8X50 ISR 45
CYL. SCREW DIN14579 M8X50 SS

014579080506S

$7,38

Unit Price

SPECIAL SCREW M10X129 HEX8 08

75603015000

$11,08

Unit Price

SPECIAL SCREW M10X152 ISK8 07

75003014000

$9,49

Unit Price

COLLAR NUT M10-SW13 ZNNI

54630044000

55530044000

$1,44

Unit Price

CHAIN SLIDING PIECE 03

54804067000

$7,38

Unit Price

BUSHING 8, 2X10X20

51103053051

$5,80

Unit Price

HH COLLAR SCREW M8X30

0025080306

$4,34

Unit Price

WASHER DIN 125 A -8.4

0125080003

$1,44

Unit Price

FLAT HEAD SCREW M. ISA45 M8X20

0019080206S

$2,89

Unit Price

PLUG SFL28 05

61003088000

$2,89

Unit Price

SUB FRAME BLACK MATT

7500300200033

Contact

COUNTERSUNK SCREW ISA45 M10X28

0019100289S

$7,38

Unit Price

FOOTREST BRACKET REAR L/S

7560304800033S

Contact

FOOTREST BRACKET REAR R/S

7560304900033S

Contact

COUNTER-SUNK SCREW ISA45 M8X30

0019080306S

$1,44

Unit Price

FOOTREST CPL. L/S REAR 03

60003050000

$86,71

Unit Price

FOOTREST CMPL. R/S REAR 03
FOOTREST CPL. R/S REAR 03

60003051000

$87,37

Unit Price

BOLT FOR FOOTREST REAR 03

60003044000

$12,53

Unit Price

RETAINING WASHER DIN 6799 - 6

0799060003

$1,44

Unit Price

ENGAGE PANEL FOOTREST R/S 03

60003052000

$7,38

Unit Price

ENGAGE PANEL FOOTREST L/S 03

60003152000

$7,38

Unit Price

FOOTPEG LS+RS CPL.

60003040033

60003040133

$207,62

Unit Price

FOOTREST L/S 08

59003040250

78003040050

$61,63

Unit Price

FOOTREST R/S 08

59003041250

78003041050

$61,63

Unit Price

PIN FOR FOOT PED 51.5X9.8 MM

54803044000

$17,54

Unit Price

FOOTREST SPRING L/S & R/S

54603041000

$7,38

Unit Price

WASHER DIN 125 A 10.5

0125100003

$2,89

Unit Price

PIN DIN 0094-3.2X25 NIRO

0094032253

0094032250

$1,44

Unit Price

FOOTREST RUBBER FRONT L/S 03

60003040010

$31,27

Unit Price

FOOTREST RUBBER FRONT R/S 03

60003041010

$31,27

Unit Price

CLOSING PANEL FRONT L/S R/S 03

60003044010

$8,57

Unit Price

SELF LOCKING NUT DIN 985 M5
SELF LOCKING NUT DIN0985-M 5

0985050003

$2,89

Unit Price

CHAIN SLIDING KIT UPPER CPL.

54804067010

$29,29

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FRAME of your KTM 690 DUKE BLACK of 2011. Let us know if you have any questions.
