FUEL PUMP

PLASTICS FOR KTM DUKE 2010

STICKERS

Item numbers

HEADLIGHT MASK BLACK MATT

7560800100033A

Contact

HH COLLAR SCREW M6X12 TX30

0912060123

0025060126

$4,34

Unit Price

AH SCREW DIN6912 M6X16 SL

0012060164

$2,89

Unit Price

THERMAL PROT. FOIL F. LOW BEAM

75608001051

Contact

THERMAL PROT. FOIL F.HIGH BEAM

75608001052

Contact

REFLECTOR YELLOW ''CEV''

58412080100

58412080300

$10,94

Unit Price

REAR FENDER BLACK MATT 07

7500801300033

Contact

SIDE COVER L/S BLACK MATT

7500804100033

Contact

SIDE COVER R/S BLACK MATT

7500804200033

Contact

RANGE CHANGE METAL NUT M5

54603048200

$7,38

Unit Price

OVAL HEAD SCREW M5X14 TX25
SCREW M5X14 TORX 25 07

58605083014

$4,34

Unit Price

SCREW FOR PLASTIC K60X20 SW6

0017060203

0017060205

$2,89

Unit Price

STORAGE COMPARTMENT

75003075000

Contact

RUBBER L=145MM

50303018000

$9,10

Unit Price

MASK SPOILER LEFT BLACK MATT

7560800300033A

$122,88

Unit Price

MASK SPOILER RIGHT BLACK MATT

7560800400033A

Contact

HAND GRIP L/S 07

75012008000

$10,28

Unit Price

HAND GRIP R/S 07

75012009000

$10,94

Unit Price

EJOT PT SCREW K50X12

0081050121

$2,89

Unit Price

FLAT HEAD SCREW ISO10642 M8X60

0991080603

$2,89

Unit Price

SPACER SUB FRAME FRONT L/S

75003065000

$2,89

Unit Price

SPACER SUB FRAME FRONT R/S

75003066000

$2,89

Unit Price

SPACER SUB FRAME REAR L/S

75003067000

$1,25

Unit Price

SPACER SUB FRAME REAR R/S

75003068000

$2,89

Unit Price

COVER NUMB. PLATE CARRIER 08

75608015010

$18,07

Unit Price

NUMBER PLATE CARRIER

75608015000

Contact

WASHER DIN9021-A 6, 4

0021060003

$2,89

Unit Price

HH COLLAR SCREW M6X30 TX30

0025060306

$4,34

Unit Price

HH COLLAR SCREW M6X20 TX30

0025060206

$4,34

Unit Price

LICENCE FITTING

60012081200

60012081300

$11,87

Unit Price

HH COLLAR SCREW M6X15 TX30

0024060156

$4,34

Unit Price

SELF LOCK. NUT DIN985-M6-A2
SELF LOCK. NUT DIN0985-M 6

0985060003

$2,89

Unit Price

OVAL HEAD SCREW DIN0966-M 5X16

0966050163

$1,44

Unit Price

WASHER 6MM

40006006000

$1,44

Unit Price

WASHER DIN0125-A 5, 3

0125050003

Contact

SELF LOCKING NUT DIN 985 M5
SELF LOCKING NUT DIN0985-M 5

0985050003

$2,89

Unit Price

REAR REFLECTOR RED

58412080000

58412080400

$7,38

Unit Price

BRACKET FOR REFLECTOR

58412080050

$8,57

Unit Price

EXPANDING RIVET CPL.

76503075100

$4,34

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
