TANK / SEAT FOR KTM DUKE 2010

FUEL PUMP

Item numbers

FUEL TANK BLACK CPL. 07

7500701304433A

$1 118,74

Unit Price

TANK PLUG 06

58407008200

$163,44

Unit Price

SPARE KEY

40011166100

76911067010

$24,58

Unit Price

HOSE 5, 4X9, 4 NBR, METER

60007026001

60007126001

$10,86

Unit Price

SEAT SCREW M6X11.5 ISA30

58407011100

0900000601200

$6,49

Unit Price

AH SCREW DIN0912-M 8X30

0912080303

$3,89

Unit Price

BEARING BUSHING OUTSIDE 03

60007060000

$17,00

Unit Price

TANK RUBBER BUSHING 03

60007065000

$11,14

Unit Price

RUBBER BUFFER

54308042000

$5,19

Unit Price

SPECIAL SCREW M8 06

62507026100

$30,30

Unit Price

GAS-LEVEL SENSOR ADV. 2006

58207080100

$122,82

Unit Price

AH COLLAR SCREW DIN 912 M5X16
AH SCREW DIN0912-M 5X16

0912050163

$2,59

Unit Price

HH COLLAR SCREW M6X12 TX30

0025060126

$5,19

Unit Price

FUEL COCK CMPL.

58507003000

58507003200

$40,60

Unit Price

O-RING 1, 78X10, 82X14, 38 2-013

0770020130

$3,89

Unit Price

FUEL HOSE WITH CLUTCH

75007116060

$83,79

Unit Price

FUEL HOSE WITH CLUTCH

75007016050

Contact

O-RING VITON F. PLUG CPC 05

58507012000

$6,49

Unit Price

SPOILER L/S BLACK MET. +DECAL

7500805000040D

Contact

SPOILER R/S BLACK MET. +DECAL

7500805100040D

Contact

HH COLLAR SCREW M6X10 TX30

0024060106

$5,19

Unit Price

SPECIAL WASHER D=16, 5MM 03

60008045000

$5,19

Unit Price

AH SCREW DIN6912 M6X12

0012060123

Contact

VARIABLE ONE-EAR CLAMP 14, 2 MM

00050142706

$5,19

Unit Price

SEAT 08

75607040000

Contact

SEAT LOCK 05

62507050000

$88,17

Unit Price

OVAL HEAD SCREW DIN0966-M 5X20

0966050203

Contact

HH COLLAR SCREW M5X12 TX30

0025050126

$5,19

Unit Price

SEAT RUBBER 6 MM

75007046020

$5,19

Unit Price

SEAT RUBBER 10 MM

75007046010

$5,19

Unit Price

RUBBER SLEEVE F.SEAT LOCK '99

58707050050

$5,19

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
