CRANKCASE FOR KTM ENDURO 2009

CLUTCH COVER

Item numbers

ENGINE CASE CPL.W.BEAR LC4 07 (0019050163S, 0025060166S, 7503000043324, 76038003000)
ENGINE CASE CPL.W.BEAR LC4 07

75030000133

$59,36

Unit Price

O-RING 6, 07X1, 78 FPM75

0770060018

$2,89

Unit Price

PLUG DIN0910-M 10X1

0910100003

Contact

SEALING RING DIN 7603 10X14X1

0603100141

$2,89

Unit Price

DOWEL, 6X8X11.5

59030023000

59030023100

$1,44

Unit Price

OIL JET 50 M6X0, 75 WS8 05

60030064050

$15,04

Unit Price

WASHER DIN 9021 A - 5.3

0021050003

$1,44

Unit Price

FLAT HEAD SCREW ISO7380 M5X8 A2 TX25

073800501001

0738050082

$1,44

Unit Price

VENTILATION CONNECTOR M16X1, 5

60030022000

$11,74

Unit Price

O-RING 18.00X2.00 NBR70

0770180020

$2,89

Unit Price

PLUG M20X1, 5 WS=13

59038017000

59038017100

$11,08

Unit Price

OILDRAIN PLUG WITH MAGNET

58030021000

58030021100

$15,96

Unit Price

CU-SEAL RING DIN7603-12X18X1, 5

58038022000

$2,89

Unit Price

CASE BUSH

75030010000

$12,13

Unit Price

CYLIND. SCR. DIN6912 M5X10 8.8

0984050103S

Contact

COVER

75030042000

$27,44

Unit Price

LOCK PIECE

75038048100

$43,55

Unit Price

BUSHING PIN

54633018400

$30,88

Unit Price

O-RING 18.00X2.00 NBR70

0770180020

$2,89

Unit Price

BUSHING PIN

59040028000

$14,77

Unit Price

DOWEL 17 X 13 X 12

51030026100

$9,10

Unit Price

DOWEL, 21X12

54830027000

54830027100

$7,38

Unit Price

MEMBRANE 07

75030003051

$3,16

Unit Price

STOP SHEET MEMBRANE 07

75030003050

$2,89

Unit Price

CYLIND.SCREW M3X8 ISO 14580 SS

0458030080

$4,34

Unit Price

SEAL RING CU DIN7603- 8X12X1

0603082121

$4,34

Unit Price

HH COLLAR SCREW M8X16 TX40

0025080166

$5,80

Unit Price

HH COLLAR SCREW M6X30 TX30

0025060306

$4,34

Unit Price

HH COLLAR SCREW M6X25 TX30

0025060256

$4,34

Unit Price

HH COLLAR SCREW M6X70 TX30

0025060706

$4,34

Unit Price

JET 125

75030058000

$7,38

Unit Price

CLAMP STD DN22

00049220121

$2,89

Unit Price

OIL HOSE BLEEDER FLANGE

76530089000

$41,96

Unit Price

CABLE TIE 200/4.6MM BLACK
CABLE TIE 200/3, 6MM BLACK

44011076200

$1,44

Unit Price

HH COLLAR SCREW M6X40 TX30

0025060406

$4,34

Unit Price

CHAIN GUARD CPL. 08

76530060044

$18,47

Unit Price

HH COLLAR SCREW M8X35 TX40

0025080356

$5,80

Unit Price

GASKET SET LC4 2007

75030099000

$289,20

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
