WATERPUMP

COOLING SYSTEM FOR KTM RALLY 2005

VALVES

Item numbers

RADIATOR L/S RALLYE 2001

58535007000

Contact

RADIATOR CAP SMALL 20, 3 PSI

58035016000

$36,29

Unit Price

RADIATOR R/S RALLYE 2001

58535008000

Contact

RADIATOR PROTECTOR CPL. L/S 01

58503007000

Contact

RADIATOR PROTECTOR CPL. R/S 01

58503008000

Contact

FLAT HEAD SCR. DIN7991-M 6X16

0991060163

$2,89

Unit Price

PLASTIC-SCREW M6X16 MM

0085060160

Contact

SELF LOCK. NUT DIN985-M6-A2
SELF LOCK. NUT DIN0985-M 6

0985060003

$2,89

Unit Price

HEX NUT DIN 934 M6

0934060003

$1,44

Unit Price

HOSE CLAMP GEMI 10-16

58335099000

$5,80

Unit Price

HOSE CLIP 18-29

10001020000

0310000902900

$2,89

Unit Price

HOSE ID 7, 5 PER METER

54435024001

Contact

CLAMP YDNAC 10128 12MM

58031005000

$4,34

Unit Price

PVC-HOSE 7X10 PER METER

55007016001

$8,57

Unit Price

CABLE TIE 200/4.6MM BLACK
CABLE TIE 200/3, 6MM BLACK

44011076200

$1,44

Unit Price

CLIP NUT M6

50235033300

54603048100

$5,80

Unit Price

BUSHING 6, 5X11, 2X10

58011039100

Contact

RUBBER SLEEVE D=12MM

41001052000

$5,80

Unit Price

WASHER DIN9021-A 6, 4

0021060003

$2,89

Unit Price

HH COLLAR SCREW M6X12 TX30

0015060123

0025060126

$4,34

Unit Price

HH COLLAR SCREW M6X16 TX30

0015060163

0025060166

$4,34

Unit Price

HH COLLAR SCREW M6X20 TX30

0015060203

0025060206

$4,34

Unit Price

SILENTBLOC 20X15-M6X10-(1)

43205062100

$19,66

Unit Price

FOAM RUBBER STRIP

58107011000

Contact

THERMOSWITCH 80-85 DG

58035045000

$53,58

Unit Price

ALU SEALRING DIN7603-14X20X1, 5

0603142015

$2,89

Unit Price

THERMO.CASE CPL.55 DEGREES 05

58535013044

Contact

O-RING 32, 00X2, 00

0770320020

$2,89

Unit Price

THERMOSTAT 55 DEGREES '94

54635017000

Contact

SCREW FOR PLASTIC D=4X18

0016040183

$2,89

Unit Price

FAN CPL. WITH HOUSING L/S 05

58535041044

Contact

FAN CPL. WITH HOUSING R/S 05

58535141044

Contact

HH COLLAR SCREW M6X10 TX30

0014060103

0024060106

$4,34

Unit Price

PLASTIC CAP

44106018000

Contact

ALU TUBE 18X22 RADIA.D./WAPU

58535020008

Contact

PREFORMED H.90°CURVE TUBE/WAPU

58535020007

Contact

PREFORMED H. 18X25/21X28 50MM

58535020005

Contact

PREFORMED HOSE 30°CURVE 18X25

58535020004

Contact

PREFORMED H.18X25/50 RAD.D-ALU

58535020006

Contact

PREFORMED H. 90°CURVE 18X26 01

58535020002

Contact

RADIATOR HOSE 12 X 3 MM

58035024001

Contact

RADIATOR BUSHING 2001

58535050000

Contact

TOOTH LOCK WASH. DIN6797-J 5, 3

0797050003

Contact

HH COLLAR SCREW M5X12 TX30

0015050123

0025050126

$4,34

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
