CYLINDER / HEAD

CRANKSHAFT / PISTON FOR KTM SUPERMOTO 2006

ENGINE VENT

Item numbers

CRANKSHAFT CPL. LC4 05

58430018300

$751,91

Unit Price

CON.ROD REPAIR KIT

58430015044

Contact

SHIM WASHER 36X48X0, 10

56530081000

$2,89

Unit Price

SHIM WASHER 36X48X0, 15

56530081100

$2,89

Unit Price

SHIM WASHER 36X48X0, 30

56530081300

$2,89

Unit Price

WOODRUFF KEY DIN6888-3X5X13

0888030050

$2,89

Unit Price

WOODRUFF KEY 5X6, 5 HARDED

6946005

$2,89

Unit Price

THRUST WASHER 30, 5X45X0, 10

56030081000

$1,44

Unit Price

THRUST WASHER 30, 7X47X0, 15

56030081100

$2,89

Unit Price

THRUST WASHER 30, 5X45X0, 30

56030081200

$2,89

Unit Price

CYL.ROLLER BEARING NJ 306 C3

58030082000

$162,74

Unit Price

CYL.ROLLER BEAR. NJ 207 ECP C3

56530123000

$127,24

Unit Price

SH.SEAL RING 30X47X7 BSL VITON

0760304772

$28,76

Unit Price

STEEL WASHER 16 X 30 X 3

58330095000

Contact

HEX NUT M16X1, 25 L/S

58430028000

Contact

LOCKING RING VSK 20

58030019000

$2,51

Unit Price

HEXAGON NUT DIN0936-M20X1, 5

0936200155

Contact

SHAFT SEAL RING 12 X 22 X 7 B

0760122270

$22,30

Unit Price

OIL SCRAPER RING 101X2, 5

58330031300

$48,43

Unit Price

TAP.COMPR.PISTON RING 101X1, 25

58330932100

$37,34

Unit Price

PISTON PIN 22 X 13 X 60

58330833000

$65,33

Unit Price

PISTON I CPL. D=101 ELKO 03

58430007100I

Contact

PISTON II CPL. D=101 ELKO 03

58430007100II

Contact

CIRCLIP 22 X 1, 6

58430074000

$13,58

Unit Price

L-RING 101X93, 5X1, 5 2000

58430032000

$64,54

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CRANKSHAFT / PISTON of your KTM 640 LC4 SUPERMOTO ORANGE of 2006. Let us know if you have any questions.
