HANDLEBAR / CONTROLS

FRAME FOR KTM ADVENTURE 2006

SIDE / MAIN STAND

Item numbers

FRAME CPL. ''EC05'' 640

5820300174430

Contact

SUB FRAME CPL. ''I3'' BLACK 06

5840300234430

Contact

PLUG 12 X 17 MM

58303002090

Contact

FOOTREST BRACKET R/S BLACK

5810300420030

Contact

FOOTRESTBRACK. REAR L/S 06

5840304800030

Contact

HEXAGON NUT DIN934 M8
HEXAGON NUT DIN0934-M 8

0934080003

$2,89

Unit Price

THERMAL PROTECTION BOW 04

58403056000

Contact

OVAL HEAD SCR. DIN7985-M 5X10

0985050103

$1,44

Unit Price

SPECIAL SCREW M8X26 WS=10

59001037000

$4,34

Unit Price

SPACER ROLLER 10, 3X20X22

58003012000

Contact

PVC CAP D=22MM

71001012100

$4,34

Unit Price

TANK SUPPORT '93

58307015000

Contact

ENGINE SUPPORT AGW '94

58303055000

Contact

ENGINE BRAC.SCREW M10X110 WS13

58403013000

Contact

COLLAR NUT M10-SW13 ZNNI

54630044000

55530044000

$1,44

Unit Price

HH COLLAR SCREW M8X16 TX40

49109481052

0025080166

$5,80

Unit Price

SELF LOCKING NUT M8 10.9

54310086200

$4,34

Unit Price

BATTERY BOX 03

58403002370

Contact

HH COLLAR SCREW M6X10 TX30

0015060103

0025060106

$4,34

Unit Price

WASHER DIN9021-A 6, 4

0021060003

$2,89

Unit Price

SILENTBLOC 20X15-M6X10-(1)

43205062100

$19,66

Unit Price

TOOTH LOCK WASH. DIN6797-A 6, 4

0797060003

$1,44

Unit Price

HEX NUT DIN 934 M6

0934060003

$1,44

Unit Price

RUBBER GROMMET 20X15-M6X8-(2)

58403002010

$16,22

Unit Price

CLIP NUT M6

54603048100

$5,80

Unit Price

AH COLLAR SCREW M10X25 ISA45

0912100250

0032100256S

$5,80

Unit Price

ENGINE BRAC.SCREW M10X160 WS13

58403014000

Contact

WASHER 10, 5 X 21 X 3

31004001100

Contact

PLUG 37MM

54606004000

$2,89

Unit Price

PLUG 37MM PERFORATED 04

54606004100

Contact

PVC-HOSE 7X10 PER METER

55007016001

$8,57

Unit Price

ANGLE PIECE '97

50303089000

$7,38

Unit Price

FOOTREST BRACKET LEFT ALU 05

58403038100

$130,01

Unit Price

FOOTREST L/S 08

59003040250

78003040050

$61,63

Unit Price

FOOTREST R/S 08

59003041250

78003041050

$61,63

Unit Price

FOOTREST RUBBER FRONT L/S 03

60003040010

$31,27

Unit Price

FOOTREST RUBBER FRONT R/S 03

60003041010

$31,27

Unit Price

CLOSING PANEL FRONT L/S R/S 03

60003044010

$8,57

Unit Price

FOOTREST SPRING L/S & R/S

54603041000

$7,38

Unit Price

PIN FOR FOOT PED 51.5X9.8 MM

54803044000

$17,54

Unit Price

WASHER DIN 125 A 10.5

0125100003

$2,89

Unit Price

PIN DIN 0094-3.2X25 NIRO

0094032253

0094032250

$1,44

Unit Price

FOOTREST REAR L/S CPL. '95

58303050044

$130,14

Unit Price

FOOT REST REAR R/S CPL.'95

58303150044

$127,87

Unit Price

SELF LOCKING NUT DIN 985 M5
SELF LOCKING NUT DIN0985-M 5

0985050003

$2,89

Unit Price

FOOTREST RUBBER L/S&R/S DUKE95

58303051000

$22,16

Unit Price

CHAIN ROLL 12X29X22, 5 '98

58403060000

$8,57

Unit Price

BUSH CHAIN ROLL 8X12X23 '98

58403060065

$4,34

Unit Price

CHAIN SLIDING PIECE BELOW '97

51103053000

$12,92

Unit Price

BUSHING 8, 2X10X20

51103053051

$5,80

Unit Price

PLASTIC CAP SFL10

54403135000

$2,89

Unit Price

LOCK WASHER 8MM

36003014000

$2,89

Unit Price

HH COLLAR SCREW M8X30

0015080303

0025080306

$4,34

Unit Price

HH COLLAR SCREW M 8X45 WS=10

0015080453

$2,89

Unit Price

PLUG DIN0910-M16X1, 5

0910160153

Contact

CU-SEAL RING 16X22X2

0603162220

$2,89

Unit Price

COUNTER-SUNK SCREW ISA45 M8X30

54510052200

0019080306S

$1,44

Unit Price

COUNTER-SUNK SCREW ISA45 M8X26

54510052100

0019080266S

$4,34

Unit Price

WASHER DIN 125 A -8.4

0125080003

$1,44

Unit Price

COVER OIL FILTER '94

58303010000

Contact

HH COLLAR SCREW M6X15 TX30

0014060153

0024060156

$4,34

Unit Price

HH COLLAR SCREW M6X10 TX30

0014060103

0024060106

$4,34

Unit Price

CLIP NUT M6

50235033300

54603048100

$5,80

Unit Price

AH SCREW DIN7984-M 6X10

0984060103

$1,44

Unit Price

SKID PLATE LIMITED CPL. 97

58412099044

Contact

ENGINE PROTECTOR BRACKET '97

58003012200

$29,59

Unit Price

RUBBER BUFFER

54308042000

$4,34

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FRAME of your KTM 640 LC4 ADVENTURE of 2006. Let us know if you have any questions.
