FRONT BRAKE MASTER CYLINDER

REAR BRAKE MASTER CYLINDER FOR KTM DUKE 2004

FRONT BRAKE CALIPER

Item numbers

FLAT HEAD SCREW DIN7991-M 8X35

0991080353

Contact

SPECIAL WASHER ALU 8 X 24 MM

58303061000

$8,00

Unit Price

FOOT BRAKE LEV. FOLDING CPL.04

58403070244

Contact

GROOVED BALL BEARING 608 2RS C3
GROOVED BALL BEAR. 608 2RS C3

0625006087

$32,73

Unit Price

FLAT HEAD SCREW DIN7991 M6X20 8.8

0991060203

0991060202

$3,89

Unit Price

BRAKE LEVER STOP LC4 03

58413048000

$8,85

Unit Price

TOOTH LOCK WASH. DIN6797-A 6, 4

0797060003

$2,59

Unit Price

RETURN SPRING

13003062000

$8,85

Unit Price

WASHER DIN 125 A -8.4

0125080003

$2,59

Unit Price

SELF LOCKING NUT DIN0985-M 8

0985080003

$3,89

Unit Price

HH SCREW DIN0933-M 8X22 8.8

0933080223

Contact

HEIM JOINT M8 W=12MM '93

58303062000

$59,63

Unit Price

HEXAGON NUT DIN934 M8
HEXAGON NUT DIN0934-M 8

0934080003

$3,89

Unit Price

PUSH ROD ALU L=178MM '93

58303068100

Contact

STEP PLATE FOR SHIFT LEVER 250

54634131000

$48,32

Unit Price

SHIFTING LEVER SPRING 250

54634032100

$5,19

Unit Price

BOLT 6X25 FOR SHIFT LEVER

54634031050

$12,00

Unit Price

MAIN BRAKE CYLINDER

54513101044

54513101144

$193,82

Unit Price

REPAIR KIT PISTON 13MM

54513150000

$71,06

Unit Price

BRAKE CYL. PROTECTOR ''BREMBO''
BRAKE CYL. PROTECTOR ''BREMBO'

54513038000

$10,71

Unit Price

COLLAR BUSHING

50213161000

$5,19

Unit Price

HH COLLAR SCREW M6X25 TX30

0015060253

0025060256

$5,19

Unit Price

CABLE TIE 200/4.6MM BLACK
CABLE TIE 200/3, 6MM BLACK

44011076200

$2,59

Unit Price

CLIP NUT M6

50235033300

54603048100

$6,49

Unit Price

CU-SEAL RING DIN7603-10X16X1

42013226000

$3,89

Unit Price

BRAKE LIGHT SWITCH REAR '98

50311051100

$56,47

Unit Price

BRAKE FLUID RESERVOIR '89

54513030044

$31,45

Unit Price

HH COLLAR SCREW M6X10 TX30

0014060103

0024060106

$5,19

Unit Price

YDNAC CLAMP 10101 (10, 4MM)

58007017000

$5,19

Unit Price

HOSE RESERVOIR 6X1, 5

58007016101

57313072001

$25,01

Unit Price

LOCTITE 243 BLUE 5 ML

6899785

$42,89

Unit Price

BRAKE FLUID DOT 4.0

306054

Contact

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the REAR BRAKE MASTER CYLINDER of your KTM 640 DUKE II YELLOW of 2004. Let us know if you have any questions.
