TIMING

OIL PUMP FOR KTM DUKE 2004

IGNITION SYSTEM

Item numbers

NEEDLEROL.DIN5402 NRA 2, 5X19, 8

0402251980

$2,59

Unit Price

HH COLLAR SCREW M6X20 TX30

0015060203

0025060206

$5,19

Unit Price

HH COLLAR SCREW M6X25 TX30

0015060253

0025060256

$5,19

Unit Price

OIL PUMP MIKUNI G-73-10

58038007700

$148,99

Unit Price

STOP DISK 8, 1 X 15 X 0, 5

58038007755

$3,89

Unit Price

TAB WASHER DIN6799-RS 6, 0

0799060000

$3,89

Unit Price

OIL PUMP GEAR 26-T

58438001000

$14,57

Unit Price

OILDRAIN PLUG WITH MAGNET

58030021000

58030021100

$17,29

Unit Price

BANJO BOLT, TYPE A DIN 7643-3 DN4 M10X1

54313025000

0076431001900

$9,85

Unit Price

VALVE PISTON D=10MM

58038028000

$57,76

Unit Price

OIL DRAIN PLUG M22X1, 5

58038019100

Contact

CU-SEAL RING DIN7603-22X27X2

58038017100

Contact

THREADED PLUG DIN 908 M12X1.5

0908120153

$6,49

Unit Price

CU-SEAL RING DIN7603-12X18X1, 5

58038022000

$3,89

Unit Price

PRESSURE SPRING L=25MM D=1MM

58038023300

$8,00

Unit Price

OIL FILTER LONG

58038005000

Contact

OIL FILTER COVER GASKET 2001

58530041000

$10,71

Unit Price

OIL FILTER COVER 2001

58030008700

Contact

HH COLLAR SCREW M6X25 TX30

0015060253

0025060256

$5,19

Unit Price

PLUG DIN0910-M16X1, 5

0910160153

Contact

CU-SEAL RING 16X22X2

0603162220

$3,89

Unit Price

AH SCREW DIN7984-M 6X10

0984060103

$2,59

Unit Price

OIL LINE FILTER-FRAME TUBE

58038234700

Contact

OIL LINE CLUTCH COVER-FRAME

58338034000

Contact

DUAL BANJO BOLT M10X1

58038033100

58038033200

$19,58

Unit Price

JET SCREW M 8 X 1 ''150''

58038130000

$19,72

Unit Price

BANJO BOLT M8X1

58038030000

58038029000

$8,00

Unit Price

SEALING RING DIN 7603 10X14X1

0603100141

$3,89

Unit Price

COPPER GASK.DIN7603- 8, 2X13X1

0603082131

$3,89

Unit Price

CU-SEAL RING 8 X 12 X 1, 5

58038032300

Contact

SCREW TYPE FILTER

58338045000

58338045100

$36,60

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the OIL PUMP of your KTM 640 DUKE II BLACK of 2004. Let us know if you have any questions.
