FRONT FORK / TRIPLE CLAMP

FRONT FORK (PARTS) FOR KTM ENDURO 2002

HANDLEBAR / CONTROLS

Item numbers

SCREW CAP M51X1, 5 CPL.

48600020S

Contact

O-RING 45X2 NBR70 SILICONIZED

46810340

$1,56

Unit Price

ADJUSTER REBOUND

48600018

$6,28

Unit Price

SCREW CAP M51X1, 5 CPL.

48600020S1

Contact

STEEL BALL D3

40540603

$1,56

Unit Price

SPRING (1, 7) L7, 9

48600028

$4,71

Unit Price

O-RING 6X1, 5 NBR70

48600044

$1,56

Unit Price

CROSS FLAT HEAD SCREW M4X6

48600058

$2,85

Unit Price

O-RING 3, 7X1, 6 NBR70

48600009

$1,56

Unit Price

O-RING 12X1, 5 NBR70

48600043

$3,13

Unit Price

TUBE TAP D4X25

48600019

$4,71

Unit Price

OUTER TUBE L=577MM D=54/57MM

43570125

Contact

ROUND-WIRE SNAP RING 53X2

43570099

$40,46

Unit Price

DU-BUSH 47 X 43 X 20

43570019

Contact

SUPPORTWASHER 45X52, 5X1, 5

43570092

$30,73

Unit Price

SHAFT SEAL SKF 43X52, 9X11, 4 BLACK

43570140

43570623

$25,44

Unit Price

SNAP RING SB53X1, 5 ACC DRAWING

43570008

$4,71

Unit Price

DIRT SCARPER SKF 43MM BLACK

43570094

43570624

$25,58

Unit Price

GUIDE BUSHING 42X44X20

43570020

43570617

$17,43

Unit Price

INNER TUBE D=43MM L=585MM

43570145

Contact

HYDR.STOP L=200 D=27, 5 CPL. 05

43570142S

Contact

O-RING 6, 3X2, 4 NBR70

48600175

Contact

ADJUSTMENT TUBE L=512MM

48600014

Contact

ADJUSTMENT TUBE L=492MM

48600094

Contact

PISTONR. D=14MM L=546MM M11X1

48600023

Contact

PISTONR. D=14MM L=526MM M11X1

48600093

Contact

* REBOUND NEEDLE

48600150

Contact

O-RING 3X1, 5 NBR70

48600046

$2,59

Unit Price

SPRING (7, 2) 4-23 NEEDLE

48600033

$8,00

Unit Price

PRELOAD BUSH 42X26, 5X2, 5

48600036

$3,13

Unit Price

PRELOAD BUSH 26, 5X42X5

48600037

$6,28

Unit Price

PRELOAD BUSH 26, 5X42X10

48600038

$4,71

Unit Price

PRELOAD BUSH 26, 5X42X1, 5

48600053

$6,28

Unit Price

SPRING 4, 0 N/MM SET D=4, 75MM

95010002S

Contact

SPRING 4, 2 N/MM SET D=4, 9MM

95010003S

Contact

SPRING 3, 6 N/MM SET D=4, 6MM

95010010S

Contact

SPRING 4, 4 N/MM SET D=4, 9MM

95010012S

Contact

SPRING 5, 0 N/MM SET D=5, 0MM

95010022S

Contact

SPRING RETAINER 33, 5X38, 2X3

43570131

$27,59

Unit Price

SCREW SLEEVE M29, 3X1+BUSH

43570132S

Contact

REBOUND SPRING D=14, 6MM L=22MM

48600015

Contact

REBOUND SPRING D=14, 6MM L=75MM

48600178

Contact

TAB REBOUND

48600151

Contact

SPRING (11, 7) 1, 5-8 VALVE

35480377

$3,13

Unit Price

CHECK VALVE 8X24X0, 1

48600062

$3,13

Unit Price

SHIM 6X12X0, 10

40540400

$3,13

Unit Price

SHIM 6X14X0, 10

40540401

$3,13

Unit Price

SHIM 6X16X0, 10

40540402

$3,13

Unit Price

SHIM 6X18X0, 10

40540403

$3,13

Unit Price

SHIM 6X12X0, 15

40540404

$3,13

Unit Price

SHIM 6X14X0, 15

40540405

$3,13

Unit Price

SHIM 6X18X0, 20

40540411

$3,13

Unit Price

SHIM 6X16X0, 25

40540414

$3,13

Unit Price

SHIM 6X10X0, 30

40540447

$3,13

Unit Price

SHIM 6X11X0, 25

40541417

$3,13

Unit Price

SHIM 6X24X0, 10

48600063

$3,13

Unit Price

SHIM 6X22X0, 10

48600064

$3,13

Unit Price

SHIM 6X20X0, 10

48600065

$3,13

Unit Price

SHIM 6X24X0, 10 DELTA

48600116

$3,13

Unit Price

SHIM 6X22X0, 1 DELTA

48600139

$3,13

Unit Price

PISTONRING 26X28X5

48600060

$8,00

Unit Price

PISTON 6, 05X27, 65X12 REBOUND

48600042

$18,45

Unit Price

NUT M6X0, 5 H6, 5 WAF10 REBOUND

40540486

$6,28

Unit Price

TUBE 29, 3X1X385 ALU

48600140

Contact

TUBE 29, 3X1X390 D=8, 5MM

48600081

$243,09

Unit Price

O-RING 41X2 NBR70 SILICONIZED YELLOW
O-RING 41X2 NBR70 SILICONIZED

43570023

$20,72

Unit Price

AXLE CLAMP L/S 260MM M8 2000

43570124

Contact

AXLE CLAMP RIGHT M8 2000

43570123

Contact

HH COLLAR SCREW M8X30

50600061

0025080306

$4,71

Unit Price

CHECK VALVE NUT M6X0, 5

40541241

Contact

SPRING (8, 5) L6, 5 VALVE

40541278

Contact

COMPRESSION, CMPL.

48600152S

48600586S3

$57,62

Unit Price

SHIM 8X24X0, 40

48600061

$3,13

Unit Price

PISTON 6X27, 8X9 COMPRESSION

48600047

$15,00

Unit Price

O-RING 21X2 NBR70

46811499

$1,56

Unit Price

O-RING 24X2 NBR70

35480320

$1,56

Unit Price

COMPRESSION, CMPL.

48600152

48600586S3

$57,62

Unit Price

NEEDLE COMPRESSION M10X1

48600153

Contact

O-RING 8X2 NBR70

48600049

$1,56

Unit Price

ROUND-WIRE SNAP RING 12X1 DIN7993 A2
ROUND-WIRE SNAP RING 12X1 DIN7

48600051

$4,71

Unit Price

ADJUSTMENT SCREW SLOT COMPRESSION
ADJUSTMENT SCREW SLOT COMPRESS

48600034

Contact

COPPER DISC 29, 5X33, 5X1

48600004

$6,28

Unit Price

RUBBER CAP 35X10 NBR80

48600141

$6,28

Unit Price

FORKOIL REZ 71 SAE 5

40540882

Contact

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FRONT FORK (PARTS) of your KTM 640 LC4-E ROT of 2002. Let us know if you have any questions.
