CRANKCASE FOR KTM ENDURO 1997

BALANCER SHAFT

Item numbers

ENGINE CASE CPL.W.TRAN.BEAR'96

58430000044

Contact

ENGINE CASE CPL.W.TRAN.BEAR'97

5843000004429

Contact

DOWEL 19 X15, 1X12

50130027000

Contact

DOWEL 17 X 13 X 12

51030026100

$9,10

Unit Price

CRANK CASE BUSH

50130010000

Contact

NEEDLE BEARING HK 2216

58033097000

$19,79

Unit Price

SHIFT MECHANISM SUPPORT LC4'94

58330011000

Contact

DOWEL 9, 8 X7X10

49030090000

49030090100

$2,89

Unit Price

HH COLLAR SCREW M6X35 TX30

0015060353

0025060356

$4,34

Unit Price

HH COLLAR SCREW M6X40 TX30

0015060403

0025060406

$4,34

Unit Price

RETAINING PLATE

56530017000

Contact

FLAT HEAD SCR. DIN7991-M 6X16

0991060163

$2,89

Unit Price

NEEDLE BEARING 12X18X12 2002

50332095000

46034027000

$11,34

Unit Price

LOCATING SCREW M8 L=23

58030080000

Contact

CU-SEAL RING 8 X 14 X 3

58030081000

$2,89

Unit Price

ENGINE CASE GASKET LC4-E '96

58430039000

Contact

OVAL HEAD SCR. DIN7985-M 5X10

0985050103

$1,44

Unit Price

GROOVED BALL B. 16003 C4 J1

0625160030

0625160031

$29,03

Unit Price

BALL BEARING 61805 C3

0625618050

$62,03

Unit Price

STOP DISK 33 X 58 X 1, 5

58440091000

Contact

CONTACT SCREW M10 '

58011081000

Contact

5833010100029

Contact

CLUTCH COVER GASKET 2001

58330025000

58530025000

$31,01

Unit Price

OIL DIPSTICK CPL. L=93MM '96

58330020144

Contact

O-RING 16, 00X3, 00 NBR 70

0770160030

$2,89

Unit Price

HH COLLAR SCREW M6X25 TX30

0015060253

0025060256

$4,34

Unit Price

HH COLLAR SCREW M6X30 TX30

0015060303

0025060306

$4,34

Unit Price

BUMP RUBBER

58333041000

Contact

* SPROCKET COVER BLACK '96

58430060000

Contact

BUSHING 6, 5X8X11

54613038150

$5,80

Unit Price

CHAIN DAMPERSHEET 17T LC4-E

58430047000

Contact

CHAIN DAMPERSHEET 15/16T LC4-E

58430047100

Contact

HH COLLAR SCREW M6X25 TX30

0015060253

0025060256

$4,34

Unit Price

OILDRAIN PLUG WITH MAGNET

58030021000

58030021100

$15,96

Unit Price

CU-SEAL RING DIN7603-22X27X2

58038017100

$4,34

Unit Price

OIL DRAIN PLUG M22X1, 5

58038019100

Contact

CU-SEAL RING DIN7603-12X18X1, 5

58038022000

$2,89

Unit Price

THREADED PLUG DIN 908 M12X1.5

0908120153

$5,80

Unit Price

PRESSURE SPRING L=25MM D=1MM

58038023300

$7,38

Unit Price

VALVE PISTON D=10MM

58038028000

$53,32

Unit Price

GASKET SET LC4-E '

58430099000

Contact

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CRANKCASE of your KTM 620 LSE 11LT BLAU of 1997. Let us know if you have any questions.
