REAR WHEEL

WIRING HARNESS FOR KTM ENDURO 1997

ACCESSORIES

Item numbers

WIRING HARNESS LC4-E CPL. '97

58411175000

Contact

WIRING HAR. REAR LC4-E/DUKE'97

58411176000

Contact

CLUTCH SWITCH '96

58411049000

Contact

START-STOP SWITCH

58411074000

Contact

BRACKET KPL. E-START '97

58411083000

Contact

STARTER RELAY '96

58411057000

Contact

DIODE S3H-15 97

58411096100

$15,00

Unit Price

* FLASHER LIGHT BRACKET

54511046000

Contact

FLASHER UNIT HELLA BRK '96

44611207100

Contact

REAR BRAKE LIGHT SWITCH '

50311051000

Contact

CLAMP RSGU 15/12

49007439000

$8,00

Unit Price

AH SCREW DIN0912-M 5X12

0912050123

$3,89

Unit Price

COVER CONNECTOR SUPPORT '93

58311083051

Contact

SELF LOCKING NUT DIN 985 M5
SELF LOCKING NUT DIN0985-M 5

0985050003

$3,89

Unit Price

HH COLLAR SCREW M6X12 TX30

0912060123

0025060126

$5,19

Unit Price

WASHER DIN0125-A 6, 4

0125060003

$2,59

Unit Price

* WIRING HARNESS-IGNITION LOCK

58311077000

Contact

LIGHT SWITCH KPL. CEV '94

58311570000

Contact

BREAK LIGHT SWITCH

51011050000

51011050100

$30,45

Unit Price

HH COLLAR SCREW M6X10 TX30

0014060103

0024060106

$5,19

Unit Price

SIDE STAND SWITCH CPL. '97

58411045000

$149,71

Unit Price

SELF LOCKING NUT M6

56509064000

Contact

HH COLLAR SCREW M6X10 TX30

0015060103

0025060106

$5,19

Unit Price

RUBBER SLEEVE D=6MM OPEN

57511027000

Contact

RUBBER GROMMET D=8MM OPEN

31008060000

$3,89

Unit Price

BATTERY 12V/8AH

58411053000

76011053100

$327,31

Unit Price

BATTERY COVER 96

58411053050

$35,48

Unit Price

BATTERY CABLE 190MM 10A '97

58411059150

Contact

STARTERCABLE 700 MM '97

58411059100

$36,17

Unit Price

FUSE 5 A 2003

58011109005

58011109105

$3,89

Unit Price

BATTERY BRACKET LC4-E/DUKE'97

58411055100

Contact

VOLT.REGULATOR-RECTIFIER 12V

58411034100

Contact

PLUG-IN FUSE, BIG 10A

58011109010

58011109110

$3,89

Unit Price

METAMOLL FOR BATTERY BRACKET

58411055150

Contact

BRACKET FOR HORN '93

58307021000

Contact

CLAMP FOR WIRING HARNESS

50211096000

Contact

HH COLLAR SCREW M6X12 TX30

0015060123

0025060126

$5,19

Unit Price

CLIP NUT M6

54603048100

$6,49

Unit Price

PLUG SFL16
COVERING CAP SFL16

50210086000

$5,19

Unit Price

DC HORN 12V NIKKO

54511060100

Contact

HH COLLAR SCREW M6X16 TX30

0015060163

0025060166

$5,19

Unit Price

STARTER RELAY WITH HOLD.RUBBER

58411058000

Contact

HOLD. RUBBER FOR STARTRELAY

58411058050

Contact

SELF LOCK. NUT DIN985-M6-A2
SELF LOCK. NUT DIN0985-M 6

0985060003

$3,89

Unit Price

GROUND CABLE D=6MM L=140MM '97

58411097100

$13,72

Unit Price

CONTACT WASHER M6 VSV-K6

58411098100

$3,89

Unit Price

CABLE TIE 300/4, 8MM BLACK

44011076305

$3,89

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the WIRING HARNESS of your KTM 620 EGS-E 35KW 11LT BLAU of 1997. Let us know if you have any questions.
