TIMING

CYLINDER HEAD FOR KTM ENDURO 1995

CYLINDER HEAD

Item numbers

* CYLINDER HEAD CPL. 350 LC4'9

57536020000

Contact

* CYLINDER HEAD CPL. 400 LC4'9

57636020000

Contact

CYLINDER HEAD CPL. 620 LC4'94

58336020000

Contact

DOWEL 9, 8 X7X10

49030090000

49030090100

$2,89

Unit Price

CU-SEAL RING 6 X 10 X 2

58036065100

$2,89

Unit Price

VALVE COVER FRONT

58036152500

Contact

VALVE COVER REAR

58036052000

58036052200

$18,64

Unit Price

VALVE COVER GASKET

58036053000

$5,80

Unit Price

CYLINDER HEAD GASKET 90, 3 MM

57530036000

$82,36

Unit Price

CYL.HEAD GASKET 95, 3 MM

58030136200

Contact

CYLINDER HEAD GASKET 101, 3 MM

58330036000

$83,81

Unit Price

CU-SEAL RING 6 X 10 X 1

58036065000

Contact

AH SCREW DIN0912-M 6X35

0912060353

$2,89

Unit Price

THREAD PIN DIN0551-M 6X25

0551060253

Contact

THREAD PIN DIN0551-M 6X30

0551060303

Contact

CAP NUT M6 STAINLESS STEEL

0587060003

61230045000

$2,89

Unit Price

COLLAR NUT M8

49030028000

$4,34

Unit Price

STUD DIN0835-M 8X40

54330043000

Contact

STUD DIN0835-M 8X35

54330043100

Contact

CU-SEAL RING 10 X 20 X 1

58036098000

$2,89

Unit Price

COLLAR SCREW M10X80 WS=13 10.9

58036099100

$14,77

Unit Price

TEMPERATURE SWITCH VDO

42011252000

Contact

0933080123

Contact

CU-SEAL RING DIN7603- 8X12X1

58038032000

Contact

CIRCLIP DIN7993-RW12

0993012000

$4,34

Unit Price

VALVE GUIDE INTAKE

58036026600

Contact

VALVE GUIDE EXHAUST

58036126600

Contact

HH PLUG M10X1 WS13

54630021000

$8,44

Unit Price

CU-SEAL RING DIN7603-10X14X1

58038032010

Contact

EXHAUST FLANGE R/S

58036040000

$43,58

Unit Price

EXHAUST FLANGE L/S

58036140000

$42,58

Unit Price

EXHAUST FLANGE GASKET

58036041000

$5,80

Unit Price

INTAKE FLANGE D=26MM

58136142026

Contact

INTAKE FLANGE D=28MM

58136142028

Contact

57536042000

Contact

INTAKE FLANGE D=38MM

58136042000

Contact

INTAKE FLANGE D=40MM

58136042040

Contact

58136142023

Contact

INTAKE FLANGE GASKET

58136043000

$4,34

Unit Price

INTAKE BOOT D=38MM 400-660 LC4

58136044100

$47,64

Unit Price

INTAKE BOOT D=39MM 540 LC4 '98

57536044000

Contact

CLAMP SM12/A60

56530061000

Contact

AH SCREW DIN0912-M 6X16

0912060163

$1,44

Unit Price

FLAT HEAD SCR. DIN7991-M 6X16

0991060163

$2,89

Unit Price

AH SCREW DIN0912-M 6X20

0912060203

$2,89

Unit Price

AH SCREW DIN0912-M 6X25

0912060253

$2,89

Unit Price

AH SCREW DIN0912-M 6X35

0912060353

$2,89

Unit Price

RETAINING PLATE

51005074000

$4,34

Unit Price

AH SCREW DIN912 M 6X60 12.9

0912060601

Contact

AH SCREW DIN912 M6X65 12.9

0912060651

Contact

SPRING WASHER DIN0137-B 6

0137060000

Contact

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CYLINDER HEAD of your KTM 620 SUPER-COMP WP/ 19KW of 1995. Let us know if you have any questions.
