GEARBOX COUNTERSHAFT

GEARBOX COUNTERSHAFT FOR KTM SXS 2002

KICK STARTER

Item numbers

COUNTER SHAFT RACING 2000

59033010000

Contact

IDLER GEAR 2.G 30-T ''36''

59033012036

Contact

NEEDLE BEAR.K 22X26X10 DIVIDED

0405222611

$16,49

Unit Price

STOP DISC 25, 2X32X1, 5

59033031000

Contact

CIRCLIP DIN0471-25X1, 2

0471250120

$2,89

Unit Price

SLIDING GEAR 6.G 21-T ''26''

59033016026

Contact

STOP DISC 25, 2X32X1, 5

59033030000

$4,34

Unit Price

IDLER GEAR 4.G 26-T ''33''

59033014033

$188,48

Unit Price

IDLER GEAR 3.G 28-T ''47''

59033013047

Contact

SLIDING GEAR 5.G 23-T ''29''

59033015029

Contact

SHIM 20X31.9X1
SHIM 20X32X1

59033080000

$2,89

Unit Price

NEEDLE BEARING K 20X26X12

0405202612

$15,43

Unit Price

IDLER GEAR 1.G 32-T ''43''

59033011043

Contact

STOP DISC 17, 2X30X1

56033030000

$5,80

Unit Price

SPACER BUSHING 12MM

54633014100

$29,56

Unit Price

FRONT SPROCKET 13?TEETH

50033029013

A46033029013

$43,68

Unit Price

FRONT SPROCKET 14?TEETH

50033029014

A46033029014

$43,68

Unit Price

FRONT SPROCKET 15-T

50033029015

$38,27

Unit Price

SCREW 10.9+SPRING WASHER

59033034044

$11,08

Unit Price

O-RING 25, 12X1, 78 NBR70

0770020220

$4,34

Unit Price

BALL BEARING 6203 JR2 C3

0625062034

0625062035

$20,45

Unit Price

CYLINDRICAL ROLLER BEARING NJ205
CYLINDRICAL ROLLER BEARING NJ2

49030023000

$105,06

Unit Price

SHAFT SEAL RING 32X45X7 BSLNBR

0760324571

$7,38

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the GEARBOX COUNTERSHAFT of your KTM 540 SXS RACING of 2002. Let us know if you have any questions.
