GEARBOX COUNTERSHAFT

KICK STARTER FOR KTM EXC 2009

GEAR SHIFTING MECHANISM

Item numbers

KICK STARTER CPL.

77033170044

$187,30

Unit Price

FLAT HEAD SCREW M. ISA45 M8X20

0019080206S

$2,89

Unit Price

WASHER 8MM GALVANIZED

54633037000

$8,57

Unit Price

SHAFT SEAL RING 19X30X7 B

0760193070

$7,91

Unit Price

DRIVING HUB

59033055000

$5,80

Unit Price

KICKSTARTER GEAR 39-T

59033051039

$115,62

Unit Price

CIRCLIP DIN0471-19X1, 2

0471190120

$1,44

Unit Price

SHIM WASHER DIN0988-17X24X0, 5

0988172405

$2,89

Unit Price

IDLER GEAR CPL.

78033053100

78033053200

$102,95

Unit Price

BUSHING PIN

78033018100

$16,22

Unit Price

KICKSTARTER SPRING

59033054000

$11,34

Unit Price

SPRINGHOLDER 08

78033074000

$4,34

Unit Price

HH COLLAR SCREW M6X12 TX30

0912060123

0025060126

$4,34

Unit Price

SHIM 20X31.9X1
SHIM 20X32X1

59033080000

$2,89

Unit Price

NEEDLE BEARING K 22X26X10 A

0405222610

$9,49

Unit Price

BUMP PART

59033069000

$18,73

Unit Price

STOP DISK 22, 2 X 30 X 1, 5

58033031000

$5,80

Unit Price

RATCHET GEAR SPRING 1, 2 MM

58033028000

$2,89

Unit Price

RATCHET GEAR KICK STARTER

78033052000

$66,78

Unit Price

HH COLLAR SCREW M6X20 TX30

0025060206

$4,34

Unit Price

CIRCLIP DIN0471-17X1

0471170010

$2,89

Unit Price

KICKSTARTER SHAFT

59033050100

$92,12

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
