CRANKCASE FOR KTM XC 2007

BALANCER SHAFT

Item numbers

ENGINE CASE 2006

59030000444

Contact

DOWEL 17 X 13 X 12

51030026100

$9,10

Unit Price

DOWEL 9, 8 X7X10

49030090000

49030090100

$2,89

Unit Price

HANGER FOR VENT HOSE

59030090000

$5,80

Unit Price

HH COLLAR SCREW M6X15 TX30

0014060153

0024060156

$4,34

Unit Price

OILDRAIN PLUG WITH MAGNET

58030021000

58030021100

$15,96

Unit Price

CU-SEAL RING DIN7603-12X18X1, 5

58038022000

$2,89

Unit Price

THREADED PLUG DIN 908 M12X1.5

0908120153

$5,80

Unit Price

DOWEL 17 X 19 X 12

59030024000

$7,38

Unit Price

PRESSURE SPRING L=25MM D=1MM

58038023300

$7,38

Unit Price

VALVE PISTON D=10MM

58038028000

$53,32

Unit Price

JET 60 DELLORTO M6X0, 75

59030054000

$18,47

Unit Price

ENGINE BREATHER TUBE 00

59031050100

$20,58

Unit Price

BLEEDER FLANGE M12X1, 5 WS=13

59030022100

$11,08

Unit Price

LOCATING SCREW M8 L=23

58030080000

Contact

CU-SEAL RING 8 X 14 X 3

58030081000

$2,89

Unit Price

NEEDLE ROLLER DIN5402 2, 5X9, 8

0402025980

$4,34

Unit Price

OIL SIGHT GLASS

59030019000

59030019200

$30,08

Unit Price

OIL FILLER CAP CMPL. M24X3

58030120000

79430020033

$11,34

Unit Price

O-RING 19, 00X3, 00 NBR

0770191015

$2,89

Unit Price

NEEDLE ROLL.DIN5402 NRB 4X9.8
NEEDLE ROL.DIN5402 NRB 4X9, 8

0402040980

$4,34

Unit Price

JET 100 BING(44-031/180) M4

59030058000

$5,80

Unit Price

WASHER DIN0125-A 5, 3

0125050003

Contact

FLAT HEAD SCREW DIN7985-M 5X 8

0985050083

$1,25

Unit Price

HH COLLAR SCREW M6X8 TX30

0015060083

0025060086

$2,89

Unit Price

RET.BRACKET F.BRAKE LEVER HUB

59030001090

Contact

O-RING 12, 00X2, 00 NBR 70

0770120020

$2,89

Unit Price

SCREW PLUG

59038014100

77038017000

$23,75

Unit Price

OIL SCREEN 11, 8X44, 5MM

59038015000

59038015100

$17,81

Unit Price

O-RING 9X1, 5 V80 SH

0770090015

07700900151

$2,89

Unit Price

SEAL RING DIN7603 12X18X3

0603121830

$2,89

Unit Price

CLUTCH COVER OUTSIDE 06

59030026000

Contact

CLUTCH COVER GASKET

59030025100

Contact

ENGINE CASE GASKET

59030039200

$52,92

Unit Price

CLUTCH COVER INSIDE CPL. 06

59030101044

Contact

CHAIN DAMPING PLATE RAC. 2005

59030047100

Contact

RADIAL SHAFT SEAL 14X24X6 B

0760142460

$13,06

Unit Price

SHAFT SEAL RING 19X30X7 B

0760193070

$7,91

Unit Price

AH SCREW DIN6912-M 6X16

0984060163

$2,89

Unit Price

GASKET F. OUTER CLUTCH COV. 06

59030027000

$10,02

Unit Price

HH COLLAR SCREW M6X45 TX30

0015060453

0025060456

$2,89

Unit Price

HH COLLAR SCREW M6X60 TX30

0015060603

0025060606

$4,34

Unit Price

HH COLLAR SCREW M6X30 TX30

0015060303

0025060306

$4,34

Unit Price

HH COLLAR SCREW M6X35 TX30

0015060353

0025060356

$4,34

Unit Price

HH COLLAR SCREW M6X75 TX30

0015060753

0025060756

$4,34

Unit Price

GASKET SET

59030099000

59030099001

$514,92

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
