CYLINDER

CRANKSHAFT / PISTON FOR KTM XC 2006

CARBURETOR

Item numbers

CRANKSHAFT CPL. 520 RAC. 2006

59030018500

Contact

CON.ROD REP.SET 250/520 RAC.00

59030015044

Contact

CYL.ROLLER BEAR.NJ206 ET2XCS46

50330082000

$127,26

Unit Price

DRIVE GEAR 32-T F.BALANC.SHAFT

59030055000

Contact

THRUST WASHER 30, 5X45X0, 10

56030081000

$2,59

Unit Price

THRUST WASHER 30, 7X47X0, 15

56030081100

$3,89

Unit Price

THRUST WASHER 30, 5X45X0, 30

56030081200

$3,89

Unit Price

WOODRUFF KEY DIN6888-3X5X13

0888030050

$3,89

Unit Price

AH SCREW DIN7984-M 6X16

0984060162

$2,59

Unit Price

SH.SEAL RING 30X47X7 BSL VITON

0760304772

$31,16

Unit Price

PRIMARY GEAR 33-T

59032000033

$193,61

Unit Price

HH NUR M20X1, 5 WS=27 LEFT

59030029100

Contact

WOODRUFF KEY 5X6, 5 HARDED

6946005

$3,89

Unit Price

RADIAL SHAFT SEAL 14X24X6 B

0760142460

$14,14

Unit Price

CIRCLIP DIN0471-25X1, 2

0471250120

$3,89

Unit Price

COLLAR NUT, M12X1, RIGHT

49030021000

49030021100

$3,89

Unit Price

SPRING WASHER DIN0137-B12

0137120000

$2,59

Unit Price

PISTON PIN BOLT 20X15, 8/12X50

59030033000

Contact

CIRCLIP C20X1, 5

59030074000

$3,89

Unit Price

PISTON I 95MM CPL. FORGED 2000

59030007000I

$781,05

Unit Price

PISTON II 95MM CPL.FORGED 2000

59030007000II

$1 071,20

Unit Price

OIL SCRAPER RING 95MM

58030631000

Contact

RECTANGULAR RING 95/87, 2X1, 25

59030032000

$56,47

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CRANKSHAFT / PISTON of your KTM 525 XC-G RACING of 2006. Let us know if you have any questions.
