Displacement

Year

Model

Finish line

Parts catalogue

Parts diagram

CRANKCASE

CRANKCASE FOR KTM SX 2000

CRANKCASE

Item numbers
CRANKCASE KTM MOTO 50 2000 SX 50 SX MINI ADVENTURE
1
3
4
5
6
6
7
8
9
10
11
12
13
14
16
17
18
19
20
20
21
21
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
37
38
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
63
64
65
66
67
68
68
68
68
69
70
71
71
72
73
74
75
76
77
78
79
81
82
83
84
86
87
88
89
90
91
92
99
99
1
ENGINE CASE CPL. '97

45030000044  

Contact
3
ENGINE CASE GASKET

45030039000  

Contact
4
TENSION PIN 14X10X8

45030023000  

Contact
5
AH SCREW DIN0912-M 6X40 A2

0912060404  

Unit Price

6
AH SCREW DIN0912-M 6X45

0912060453  

Unit Price

7
AH SCREW DIN0912-M 6X50

0912060503  

Contact
8
AH SCREW DIN0912-M 6X55

0912060553  

Unit Price

9
* CLUTCH COVER

45030001000  

Contact
10
GASKET CLUTCH COVER

45030025000  

Contact
11
* IGNITION COVER

45030002000  

Contact
12
* RETAINING SPRING

45030092000  

Contact
13
* IGNITION COIL CPL.

45039006000  

Contact
14
FLYWHEEL

45039005000  

Contact
16
* CYL. BASE GASKET

36330030000  

Contact
17
CYLINDER HEAD

45030006000  

Contact
18
* CYL. HEAD GASKET

36330036000  

Contact
19
STUD BOLT M6X112-25/15

36330042000  

Contact
20
HEX NUT DIN 934 M6

0934060003  

Unit Price

21
WASHER DIN0125-A 6, 4

0125060003  

Unit Price

22
INTAKE FLANGE FOR DELLORTO

36330050000  

Contact
23
GASKET FOR INTAKE PIPE

49130438000  

Contact
24
RUBBER GASKET

45030091000  

Contact
25
* RUBBER FOR FLYWHEEL

45030095000  

Contact
26
* SECURING GUIDE

45030047000  

Contact
27
OIL LEVEL CONTR. PLUG M14X1.25

15130020000  

Contact
28
SEAL RING 14, 2X20X1

15130021000  

Contact
29
HH SCREW DIN0933-M 8X10

0933080103  

Unit Price

30
SEAL RING 8X14X1 AI

45038017000  

Unit Price

31
% CRANKSHAFT STROKE 41, 7MM

45030018000  

Contact
32
CON. ROD REPAIR S5GS '98

45030015500  

Contact
33
* NEEDLE CAGE 12X15X15

45030034000  

Contact
34
* CIRCLIP

45030074000  

Contact
35
PISTON CPL. 39MM

45030007000  

Contact
36
PISTON RING D=39MM

36330031000  

Contact
37
BALL BEARING 6203 TN9.C3

0625062031  

Contact
38
* RADIAL SEAL RING 17X35X8

15130086000  

Contact
39
WOODRUFF KEY DIN6888-2, 5X3

0888025030  

Unit Price

40
* HH-NUT M8X14, WS=15

16030028000  

Contact
41
% CLUTCH HUB 52-Z W.PRIM. 15-Z

45032001000  

Contact
42
INNER CLUTCH HUB

45032002000  

Contact
43
BUSHING SLEEVE

16032011000  

Contact
44
* CLUTCH SPRING

45032005000  

Contact
45
JOINT FOR BLOCKS

45032008000  

Contact
46
ROLLER 3X13, 8

45032045000  

Contact
47
* BUSHING 15X18X18

16032095000  

Contact
48
STARTING SHAFT

45033050000  

Contact
49
* KICKST. RATCHET

45033052000  

Contact
50
SPRING

45033056000  

Contact
51
CLUTCH HUB CPL. MORINI '97

45032002044  

Contact
52
STOP SCREW M8

16233039000  

Contact
53
RUBBER 10X26X18

16233040000  

Contact
54
* GROUND PLATE IGNITION COIL

45039003000  

Contact
55
* KICKSTARTER RUBBER

45033076000  

Contact
56
HH SCREW DIN0933-M 7X25

0933070253  

Unit Price

57
* KICKSTARTER SPRING

45033054000  

Contact
58
KICKSTARTER SPROCKETS

45033051000  

Contact
59
PLASTIC CAP KICKSTARTER

45033077000  

Contact
60
O-RING 12X 2 NBR 70

0770012020  

Contact
61
* WASHER 8, 4X25X0, 4

45033078000  

Contact
62
COUNTER SHAFT

45033002000  

Contact
63
BALL BEARING 6202-2RSH/C3

0625062027  

0625062028

Unit Price

64
* RADIAL SEAL RING 15X24X5

15133028000  

Contact
65
CHAIN SPROCKET 11-Z

45033029000  

Contact
66
WASHER 12, 2X20X1, 8

15133031000  

Contact
67
RUBBER CAP

45039008000  

Contact
68
* WASHER 15X22X0, 4

45033022000  

Contact
69
CYLINDER + PISTON

45030009000  

Contact
70
CIRCLIP 14X1, 2

36333096000  

Contact
71
SHIM 16X25X0, 25

45033023000  

50180032

Unit Price

72
CIRCLIP DIN0471-16X1

0471160150  

Contact
73
WASHER DIN0125-A 5, 3

0125050003  

Contact
74
SCREW M4X10

45030090000  

Contact
75
SPARK PLUG BOSCH W 4 AC

45039093004  

Contact
76
* SPARK PLUG CONNECTOR

45039090000  

Contact
77
TOOTH LOCK WASH. DIN6797-J 5, 3

0797050003  

Contact
78
EXHAUST GASKET ENGINE S5-E

45030046000  

Contact
79
AH SCREW DIN0912-M 5X12

0912050123  

Unit Price

81
CIRCLIP 17, 5X1, 2

45033024000  

Contact
82
* COMP. RING D=39MM

36330032000  

Contact
83
* PISTON PIN 8X12X31, 4

15130033000  

Contact
84
AH SCREW DIN0921-M 6X60

0912060603  

Contact
86
AH SCREW DIN0912-M 5X20

0912050203  

Unit Price

87
HH SCREW DIN0933-M 6X25

0933060253  

Unit Price

88
HH-NUT M12X1, 25 6MM HIGH

15133032000  

Contact
89
* STARTING LEVER

45033070000  

Contact
90
SELF LOCKING NUT M 6 COPPER

51010086000  

Contact
91
HH SCREW DIN0933-M 6X20

0933060203  

Unit Price

92
HH-NUT M6 36MM HIGH WS=12

45030079000  

Contact
99
GASKET SET GASKETS

45030099000  

Contact
99
GASKET SET SEAL RINGS

45030099100  

Contact
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CRANKCASE of your KTM 50 SX MINI ADVENTURE of 2000. Let us know if you have any questions.

Genuine parts for KTM 50 SX MINI ADVENTURE 2000
