TANK / SEAT

PLASTICS FOR KTM SXR 1997

STICKERS

Item numbers

REAR FENDER/SUB FRAME

45008013000

Contact

AIRFILTER 122X59X15 MM
AIRFILTER 120X58X15 MM

45006015000

Contact

FILTER FRAME

45006016000

Contact

SPECIAL SCREW Z 5X16

0016050153

Contact

COLLAR BUSH L=21 MM

45007013050

Contact

COLLAR BUSH L=38, 5 MM

45007013051

Contact

RUBBER STRIP 85X25X3 MM

54601097000

$1,44

Unit Price

PAST MOUNT QUICK LOCK
QUICK RELEASE LATCHPLATE

45007040050

$5,80

Unit Price

QUICK RELEASE CPL. '96

58307040551

$34,18

Unit Price

SHEET MET.SCR.DIN7981- 3, 5X16

0981350163

$1,44

Unit Price

AH SCREW DIN0912-M 8X120

0912081203

Contact

WASHER DIN 125 A -8.4

0125080003

$1,44

Unit Price

HEXAGON NUT DIN934 M8
HEXAGON NUT DIN0934-M 8

0934080003

$2,89

Unit Price

HH COLLAR SCREW M6X35 TX30

0015060353

0025060356

$4,34

Unit Price

WASHER DIN9021-A 6, 4

0021060003

$2,89

Unit Price

CLIP NUT M6

54603048100

$5,80

Unit Price

* NUMBER PLATE 50 SXR

45008007000

Contact

HH COLLAR SCREW M6X12 TX30

0015060123

0025060126

$4,34

Unit Price

FENDER FRONT 50 SXR '98

45008010000

Contact

HH COLLAR SCREW M6X10 TX30

0014060103

0024060106

$4,34

Unit Price

AIRFILT.BOOT-DELL ORTO 40/35MM

45006026000

Contact

* AIRFILTER BOOT-MIKUNI 32/35

45006026100

Contact

GUIDE FOR BRAKE HOSE

58011008000

Contact

OVAL HEAD SCR. DIN7985-M 5X10

0985050103

$1,44

Unit Price

SELF LOCKING NUT DIN 985 M5
SELF LOCKING NUT DIN0985-M 5

0985050003

$2,89

Unit Price

SEAT BLACK

45007040000

Contact

HOSE CLAMP 25-40 SGT 4
CLAMP 25-40 SGT 4

10001120000

$7,51

Unit Price

HOSE CLAMP 30-45 SGT

54305058000

$7,38

Unit Price

* REDUCTION RING PVC 59/40 MM

49106826000

Contact

RETAINING PLATE

45008007050

Contact

CLIP NUT M6

50235033300

54603048100

$5,80

Unit Price

SPLASH PROTECTOR 50 SXR

45006010000

Contact

CABLE TIE 300/4, 8MM BLACK

44011076305

$2,89

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the PLASTICS of your KTM 50 SXR PRO JUNIOR of 1997. Let us know if you have any questions.
