SHOCK ABSORBER (PARTS)

SHOCK ABSORBER (PARTS) FOR KTM ATV 2010

SWINGARM

Item numbers

MONOSHOCK LOWER PART

46180654SA6

Contact

MONOSHOCK UPPER PART

46180728SA

Contact

COMPRESSION CPL.

50180213S6

$481,93

Unit Price

LOCK NUT SHOCK M54X1, 5

46180766

$37,87

Unit Price

ADJUSTMENT NUT SHOCK M54X1, 5

46180765

$23,80

Unit Price

SPRING 100-55

91010297S

Contact

WASHER 58, 6X73, 6X1, 5

50180410

$5,80

Unit Price

SPRING RETAINER 52, 5X76X5

46180787

Contact

BALL JOINT BEARING KIT TOP 12MM

R12012

R12012T

$50,41

Unit Price

DISTANCE BUSH 12X15/18/24, 5X10, 5
DISTANCE BUSH 12X15/18/24, 5X10

46180007

$25,07

Unit Price

COPPER WASHER 55X2 RVS

46180513

Contact

REPAIR KIT

R15007

Contact

ROUND-WIRE SNAP RING 49X1, 5
ROUND-WIRE SNAP RING 49X1, 8

46810010

$4,34

Unit Price

(59) 74-200 D 11, 25 ORANGE

91010291

Contact

SPRING 78-200

91010298S

Contact

SPRING 70-200

91010305S

Contact

SPRING RETAINER D74

46180512

Contact

HS CYLINDER-HEAD SCREW R1/8 L8

50180095

$3,42

Unit Price

SHOCK ABSORBER FLUID SAF 1579A

50180342

Contact

RUBBER CAP DO NOT OPEN 22X5, 5 NBR
RUBBER CAP DO NOT OPEN 22X5, 5

46811208

$4,34

Unit Price

PLUG SCREW M5X6 CPL.

36120151

36120151ST

$5,80

Unit Price

O-RING 5, 28X1, 78 HNBR70 RED

46810893

S208600003000FB

$0,91

Unit Price

STICKER WP CLEAR 35X55

52000086

Contact

STICKER WARNING 27X55

52000012

Contact

PISTON RING 43, 95X45, 95X8

46811206

$25,07

Unit Price

BUMP STOP RUBBER W-60 D18

50180120

Contact

SEPARATION BUSH 17X12X18

46180339

Contact

REBOUND DISC H=0

46180179

Contact

SEAL SUPPORT 46X28 CMPL.

46180669S

S614620000S0000

$99,59

Unit Price

O-RING 37X, 82X1, 78 VITON70 GREEN
O-RING 37X, 82X1, 78 VITON70 GRE

46810035

$2,89

Unit Price

PISTON ROD NUT M10X1

46180356

$10,94

Unit Price

PISTON 5X4, 5X/6X6

46180441

Contact

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
