OIL PUMP

IGNITION SYSTEM FOR KTM EXC 2015

ELECTRIC STARTER MOTOR

Item numbers

IGNITION COVER

7813000230015

$149,68

Unit Price

GASKET - IGNITION COVER

78130040000

$20,58

Unit Price

PULSE GENERATOR KOKUSAN 4K3-A/B
PULSE GENERATOR KOKUSAN 4K3-A/

59039034000

$126,05

Unit Price

SPARK PLUG CONNECTOR

78039090100

$53,03

Unit Price

SPARK PLUG M12X1, 25 LKAR8AI-9

75039093000

$29,16

Unit Price

HH COLLAR SCREW M5X16 TX30

0025050166

$2,89

Unit Price

NEEDLE ROLL.DIN5402 NRB 4X9.8
NEEDLE ROL.DIN5402 NRB 4X9, 8

0402040980

$4,34

Unit Price

FLAT HEAD SCREW ISA25 M4X10

0019040106S

$1,44

Unit Price

RETAINING PLATE

81230002010

$11,87

Unit Price

IGNITION COIL
IGNITIONCOIL IG3826 KOKUSAN'96

58439006000

$106,51

Unit Price

ROTOR

78039205000

78039205100

$223,60

Unit Price

STATOR

83039004000

$329,72

Unit Price

SPRING WASHER DIN0137-B12

0137120000

$1,44

Unit Price

COLLAR NUT, M12X1, RIGHT

49030021000

49030021100

$2,89

Unit Price

WOODRUFF KEY DIN6888-3X5X13

0888030050

$2,89

Unit Price

HH COLLAR SCREW M5X30 TX30

0025050306

$2,89

Unit Price

HH COLLAR SCREW M6X16 TX30

0026060186

0025060166

$4,34

Unit Price

HH COLLAR SCREW M6X25 TX30

0025060256

$4,34

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the IGNITION SYSTEM of your KTM 500 EXC of 2015. Let us know if you have any questions.
