CRANKSHAFT / PISTON FOR KTM XC-W 2013

CLUTCH

Item numbers

CRANKSHAFT CPL.

78730018000

78730218000

$1 473,37

Unit Price

CON. ROD. REP. KIT

78730015044

Contact

PISTON I D=95MM

78730007100I

$457,74

Unit Price

PISTON II D=95MM

78730007100II

$457,74

Unit Price

COMPRESSION RING

78130030000

$57,14

Unit Price

PISTONRING

78130032100

$57,67

Unit Price

PISTON PIN

78130033000

$97,93

Unit Price

CIRCLIP

77330074000

$18,47

Unit Price

BALL BEARING 6207 TM-SX07E 39

0625062071

$74,57

Unit Price

NUT PRIMARY WHEEL

78030029200

Contact

PRIMARY GEAR

78132000032

Contact

TIMING GEAR

78036014200

78036014300

$57,41

Unit Price

WOODRUFF KEY DIN6888-3X3, 7

0888030037

$2,89

Unit Price

SHAFT SEAL RING 35X47X7 VITON

0760354774

$16,75

Unit Price

WOODRUFF KEY DIN6888-3X5X13

0888030050

$2,89

Unit Price

CRANKSHAFT REPAIR KIT

00050002308

78730218088

$173,70

Unit Price

PISTON KIT GR.I 500 ENDURO

00050000211

78730007210 I

$677,68

Unit Price

PISTON KIT GR.II 500 ENDURO

00050000212

78730007210 II

$677,68

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CRANKSHAFT / PISTON of your KTM 500 XC-W of 2013. Let us know if you have any questions.
