GEARBOX COUNTERSHAFT

GEAR SHIFTING MECHANISM FOR KTM SMR 2024

WATERPUMP

Item numbers

SHIFT LEVER CMPL.
SHIFT LEVER CPL.

79234031100

$144,79

Unit Price

HH COLLAR SCREW M6X15 TX30

0024060156S

$2,89

Unit Price

SHAFT SEAL RING 14X24X6B VITON

0760142461

$9,36

Unit Price

NEEDLE SLEEVE HK 1412 14X20X12

54632095000

$9,89

Unit Price

STOP DISK 14X30X1

54634050000

$2,89

Unit Price

RETURN SPRING 03

54834014000

$5,80

Unit Price

SPRING GUIDE

54634020000

$9,10

Unit Price

TENSIONING SPRING 0, 8MM

56534013100

$1,44

Unit Price

SHIFT SHAFT CPL.

A46034005033

$53,71

Unit Price

COMPRESSION SPRING L=25MM D=0.9MM
COMPRESSION SPRING L=25MM D=0.

58038023400

$1,44

Unit Price

SHIFT FORK SHAFT (L=66?MM)
SHIFT FORK SHAFT (L=66 MM)

A46034020000

$11,08

Unit Price

SHIFT STAR CMPL.

A46034015000

$29,69

Unit Price

SHIFT DRUM 5 GEAR

A47034012000

$80,64

Unit Price

HH COLLAR SCREW M6X30 TX30

0025060306S

$4,34

Unit Price

DETENT ARM CMPL.

A46034024044

$16,36

Unit Price

HH COLLAR SCREW M5X25 TX30

0025050256S

$1,44

Unit Price

SLEEVE FOR LOCKING LEVER

54634052300

$4,34

Unit Price

LOCKING LEVER SPRING 03

54834023000

$4,34

Unit Price

SHIFT FORK SHAFT (L=93?MM)
SHIFT FORK SHAFT (L=93 MM)

A46034019000

$11,74

Unit Price

SHIFTING FORK 4TH/5TH GEAR

79234001000

$109,68

Unit Price

WASHER DIN 9021 A - 5.3

0021050003

$1,44

Unit Price

SHIFTING FORK 2ND GEAR

79234002000

$109,81

Unit Price

BALL BEARING 61805 C3

0410002500700

0625618050

$62,03

Unit Price

PAIR NORDLOCK WASHER M6

50233041500

$5,80

Unit Price

SHIFTING FORK 1ST/3RD GEAR

79234003000

$109,81

Unit Price

NEEDLE ROLLER DIN5402 6X14, 8

0402061480

$5,80

Unit Price

FRICTION BEARING CONTROLLER

79234012010

$32,46

Unit Price

MAGNET BRACKET CMPL.
MAGNET HOLDER CPL.

79234012020

$82,88

Unit Price

GEAR POSITION SENSOR

79211023000

$171,32

Unit Price

SHIELD GEAR POSITION SENSOR

A46011024000

$9,36

Unit Price

HEX COLL. SCREW M5X14 ISA30 SELF-LOCKING
HEX COLL. SCREW M5X14 ISA30 SE

0025050146S

$1,44

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the GEAR SHIFTING MECHANISM of your KTM 450 SMR of 2024. Let us know if you have any questions.
