FRONT FORK / TRIPLE CLAMP

FRONT FORK (PARTS) FOR KTM XC-W 2016

HANDLEBAR / CONTROLS

Item numbers

AXLE CLAMP L/S + TUBE CPL.

48601437S1

$735,27

Unit Price

AXLE CLAMP R/S + TUBE CPL.

48601438S1

$703,40

Unit Price

FORK OUTER TUBE 49, 13X577 DT54 DB60 NATU
FORK OUTER TUBE 49, 13X577 DT54

48600736

$707,12

Unit Price

SPRING 3, 8N/MM SET D=4, 9MM

91410012S

$223,07

Unit Price

SPRING 4, 0N/MM SET D=5, 0MM

91410013S

$346,70

Unit Price

SPRING 4, 2N/MM SET D=5, 0MM

91410014S

$202,79

Unit Price

SPRING 4, 4N/MM SET D=5, 1MM

91410015S

$223,07

Unit Price

SPRING 4, 6N/MM SET

91410016S

$223,07

Unit Price

SPRING 4, 8N/MM SET

91410017S

$229,93

Unit Price

SPRING TENSIONER SET
SPRING SPACER KIT

R14026

$118,25

Unit Price

SCREW CAP M51X1, 5 REBOUND CPL.

48601561E

48601561S

$116,82

Unit Price

ADJUSTER REB. RED CPL.

48601118S

48601118ST

$5,71

Unit Price

CROSS COUNTERSUNK HEAD SCREW M4X8
CROSS COUNTERSUNK HEAD SCREW M

48600481

$3,13

Unit Price

O-RING 3X1, 5 NBR70

48600046

$2,59

Unit Price

O-RING 45X2 NBR70 SILICONIZED

46810340

$1,56

Unit Price

HH COLLAR SCREW M8X25

0025080256

$3,13

Unit Price

SEAL KIT 48MM SKF BLACK

R14040

RP10048T

$102,09

Unit Price

FORK REPAIR KIT 48MM OFFROAD (R14047T, RP10048T)
FORK REPAIR KIT 48MM OFFROAD

R14063

$144,98

Unit Price

TUBE 23X350

48600763

$114,67

Unit Price

ADAPTER 23X28X70

48600764

$34,16

Unit Price

SCREW SLEEVE M27X0, 8

48600830S

$50,30

Unit Price

SPRING (13, 9) 17-32 REBOUND CPL.
SPRING (13, 9) 17-32 REBOUND CP

48600511S

Contact

TAP 6X46 REBOUND

48600576

$19,49

Unit Price

SPRING (11, 7) 1, 5-8 VALVE

35480377

$3,13

Unit Price

PISTON REBOUND + PISTON RING

48600575S

$44,89

Unit Price

NUT M6X0, 5 H6, 5 WAF10 REBOUND

40540486

$6,28

Unit Price

STOP 12, 4X31, 9X200 CPL.

48600557S

$63,43

Unit Price

PISTON ROD 12X554

48600568

$151,71

Unit Price

ADJUSTMENT TUBE 6X520

48600559

$20,72

Unit Price

NEEDLE 4, 5X43, 6 CPL.

48600277S

$13,72

Unit Price

NUT VALVE M6X0, 5 H6, 5 WAF17

48600163

$4,71

Unit Price

SPRING (8, 5) L6, 5 VALVE

48600202

$3,13

Unit Price

PISTON 6X27, 8X9 COMPRESSION CPL.
PISTON 6X27, 8X9 COMPRESSION CP

48600047S

$23,01

Unit Price

COMPRESSION, CMPL.

48600586E

48600586S3

$57,62

Unit Price

RUBBER CAP 35X10 NBR80

48600141

$6,28

Unit Price

FUCHS GREASE IPR (250G)

T511

T14034

$52,90

Unit Price

FORK FLUID VISCOSITY 4.0 5L
FORK OIL SAE4 5L

48601166S1

$228,79

Unit Price

O-RING KIT FORK 48MM

R14064

$27,01

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
