HANDLEBAR / CONTROLS

FRAME FOR KTM RALLY 2013

ENGINE GUARD

Item numbers

FRAME 450 RALLY 2011

7630300100090

Contact

FOOTREST BRACKET RIGHT 07

76203039000

Contact

FOOTREST BRACKET LEFT 07

76203038000

Contact

AH SCREW DIN0912-M 8X30

0912080303

$2,89

Unit Price

LOCK WASHER 8MM

36003014000

$2,89

Unit Price

CHAIN SLIDING PART 11

76304066000

Contact

BUSHING 8, 2X10X20

51103053051

$5,80

Unit Price

HH COLLAR SCREW M8X35 TX40

0025080356S

$4,34

Unit Price

FOOTREST RIGHT RALLY 07

76203041250

$152,71

Unit Price

FOOTREST LEFT RALLY 07

76203040250

$163,14

Unit Price

PIN FOR FOOT PED 51.5X9.8 MM

54603044000

54803044000

$17,54

Unit Price

FOOTREST SPRING L/S & R/S

54603041000

$7,38

Unit Price

WASHER DIN 125 A 10.5

0125100003

$2,89

Unit Price

PIN DIN 0094-3.2X25 NIRO

0094032253

0094032250

$1,44

Unit Price

RUBBER GROMMET 30X20-M8X20

76305062000

Contact

RANGE CHANGE METAL NUT M8

54603048000

$5,80

Unit Price

RADIATOR STRUT

76203005030

Contact

FUEL TANK SUPPORT PLATE

76203002420

Contact

ENGINE SUPPORT RIGHT 11

76303006000

Contact

ENGINE SUPPORT LEFT 11

76303005000

Contact

CROSS MEMBER CPL. 08

76203005040

Contact

RUBBER INSERT

76203005031

$36,55

Unit Price

BUSH ENGINE SUPPORT

76203005050

Contact

HH COLLAR SCREW M8X35 TX40

0025080356

$5,80

Unit Price

JOINT PLATE SEAT 07

76203001066

Contact

SPECIAL SCREW M6X13 WS=8 10.9

59009062013

Contact

ADAPTER MONOSHOCK ANCHOR BOLT

76203001072

Contact

BUSHING

76304266001

Contact

AH SCREW DIN0912-M10X16

0912100163

Contact

PAIR OF WASHERS M10 NORDLOCK

50233041100

$5,80

Unit Price

HH COLLAR SCREW M8X20

0025080206

$2,89

Unit Price

ELASTOMER BEARING

76203018000

Contact

COLLAR BUSH FOR ELAST.BEARING

76203019000

Contact

COLLAR NUT M10-SW13 ZNNI

54630044000

55530044000

$1,44

Unit Price

AH SCREW DIN 912 M10X150 10.9

0912101503

$14,24

Unit Price

BRACKET OILFILTER

76303001089

Contact

FIXING PLATE VOLT. REGULATOR

76303001074

Contact

HH COLLAR SCREW M6X40 TX30

0025060406

$4,34

Unit Price

SLEEVE FOR CHOKE CABLE

76202095051

Contact

CHAIN SPROCKET COVER

76303096000

Contact

STEERING HEAD LOCK CPL. ZADI

71003007000

$45,26

Unit Price

CHOKE-CABLE L = 235 07

76202095000

Contact

SPACER BUSHING CHAIN GUARD

76330047005

Contact

BUSHING TANK RIGHT

76303005041

Contact

FIXING SCREW TANK REAR

58512068100

Contact

NUT F.TANK BRAKET REAR

60512063050

$37,48

Unit Price

HH COLLAR SCREW M8X45 TX40

0025080456

$5,80

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FRAME of your KTM 450 RALLY FACTORY REPLICA of 2013. Let us know if you have any questions.
