FRONT WHEEL

REAR WHEEL FOR KTM RALLY 2011

WIRING HARNESS

Item numbers

REAR WHEEL RALLY CPL.

76210001044

Contact

REAR WHEEL HUB CPL.

75310010044

7531001004491

$428,20

Unit Price

BEARING SPACER TUBE L=106MM 07

75310011000

$30,22

Unit Price

GROOVED BALL BEAR. 6205-2RSHC3HMTF7
GR.BALL BEAR. 6205-2RSHC3HMTF7

0625062052

$43,55

Unit Price

CIRCLIP DIN0472-52X2

0472052200

$4,34

Unit Price

RADIAL SHAFT SEAL 30X52X7
SHAFT SEAL RING 30X52X7

0760305271

$7,38

Unit Price

SPACER BUSH. REAR WHEEL R/S 06

60110013000

$32,46

Unit Price

SPACER RING 03

60010015000

$14,90

Unit Price

RIM 2.50X18''

7621007000030

Contact

SPOKE M5X217-17G 18'' DACRO

75310072217

Contact

SPOKE M5X207-27G 18'' DACRO

75310172207

Contact

SPOKE NIPPLE QUADRAX M5

58309072100

60310072200

$2,89

Unit Price

TUBE 110/100C-18

50310075100

$42,12

Unit Price

TUBE PROTECTOR 18" AND 19"
RIM BAND 18'' AND 19''

50310073200

$18,73

Unit Price

REAR SPROCKET ORANGE 44-T

5841005104404

$142,79

Unit Price

REAR SPROCKET ORANGE 46 T.

5841005104604

$142,79

Unit Price

REAR SPROCKET ORANGE 48-T

5841005104804

$142,79

Unit Price

REAR SPROCKET ORANGE 49-T

5841005104904

$142,79

Unit Price

REAR SPROCKET ORANGE 50-T

5841005105004

$129,59

Unit Price

REAR SPROCKET ORANGE 51-T

5841005105104

$142,79

Unit Price

COUNTER-SUNK SCREW ISA45 M8X26

0019080266S

$4,34

Unit Price

SELF LOCKING NUT M8 10.9

54310086200

$4,34

Unit Price

SPROCKET SUPPORT CPL. SILVER

7501005004491

$309,26

Unit Price

SPACER BUSH. SPROCKET SUPP. 06

60110012000

$28,37

Unit Price

NILOS RING 6006AV

60110016000

$13,72

Unit Price

BALL BEARING 6006 DDU2CG23S6NM

0625060060

$26,39

Unit Price

SPACER BUSH. SPR. SUPP. IN. 06

60110014000

$24,54

Unit Price

RUBBER DAMPING BLOCK 91
RUBBER DAMPING BLOCK '91

54610459000

$11,34

Unit Price

BRAKE DISC REAR D=240MM

76510060000

Contact

SPECIAL SCREW M6X13 WS=8 10.9

59009062013

Contact

WHEEL SPINDLE REAR CPL.

76210081044

Contact

CHAIN TENSION ADJUSTER, RIGHT, LC8
CHAIN TENSIONER R/S LC8 03

60010084000

$32,20

Unit Price

COLLAR NUT WH. SPINDLE REAR 03

60010086000

$20,58

Unit Price

HH COLLAR NUT M10X1, 25 WS=13

58414030000

$2,89

Unit Price

SCREW M10X1.25X50 WS10

50304040100

$7,38

Unit Price

CHAIN DID 118 LINKS

78010167118

78010267118

$177,40

Unit Price

RIVETING LINK FOR 78010267118

78010166100

78010266100

$18,73

Unit Price

PLUG SFL16
COVERING CAP SFL16

50210086000

$4,34

Unit Price

RIM LOCK VM4 (2.50'')

56410100100

$43,68

Unit Price

NUT FOR WHEEL HOLDER

50310090050

77110090050

$7,38

Unit Price

REAR WHEEL REP. KIT

75010015000

$117,07

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the REAR WHEEL of your KTM 450 RALLY FACTORY REPLICA of 2011. Let us know if you have any questions.
