FRONT WHEEL

REAR WHEEL FOR KTM ATV 2010

WIRING HARNESS

Item numbers

HH COLLAR NUT M10X1, 25 WS=13

58414030000

$2,89

Unit Price

RIM REAR SX 09

83510070000

Contact

SELF LOCK.NUT DIN0985-M18X1, 5

0985181503

$4,34

Unit Price

TENSIONER RAIL DIN6796 D=19

83010021000

Contact

SPACER BUSHING

83010013000

Contact

REAR WHEEL HUB CPL.

83010069044

Contact

CIRCLIP REAR AXLE

83510063000

Contact

AH SCREW DIN0912-M 6X30

0912060303

$2,89

Unit Price

TENSION NUT

83010064000

Contact

HH COLLAR SCREW M8X16 TX40 SL

0025080166S

$4,34

Unit Price

BRAKE DISK SUPPORT 08

83010062000

$180,43

Unit Price

BRAKE DISK REAR D=200 MM

83010060000

Contact

SPECIAL NUT BRAKE DISK FIXING

83010060050

$5,80

Unit Price

WHEELBOLT

83009016000

$36,16

Unit Price

O-RING 39, 34X2, 62

0770039026

07700390261

$2,89

Unit Price

REAR AXLE SX

83510016000

$911,75

Unit Price

FL.HEAD SCREW M10X1, 25 L=27 03

60003004027

$5,80

Unit Price

SPROCKET 38T

83010051038

$90,14

Unit Price

SPROCKET SUPPORT 08

83010050000

$192,71

Unit Price

CIRCLIP REAR AXLE SPROCKET

83510063100

Contact

SELF LOCK.NUT M10X1, 25

0982101253

$2,89

Unit Price

CHAIN 5/8X1/4'' MX

50310165118

$118,79

Unit Price

CONNECTING LINK FOR 50310165118
CONNECTING LINK F. 50310165118

50310166000

$9,59

Unit Price

VALVE

83009076000

Contact

CONUSRING REAR AXLE

83010014000

$19,26

Unit Price

RIM LOCK REAR ATV SX

83510090000

Contact

HH COLLAR SCREW M6X20 TX30

0025060206

$4,34

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
