Displacement

Year

Model

Finish line

Parts catalogue

Parts diagram

HANDLEBAR / CONTROLS

FRAME FOR KTM DUKE 2017

SIDE / MAIN STAND

Item numbers

FRAME DUKE 18 ORANGE

93003001000EB

93003001100EB

$1 623,98

Unit Price

FOOTREST BRACKET FRONT LEFT

93003038000

$217,13

Unit Price

HEEL PROTECTOR LEFT

93003048050

$7,38

Unit Price

SCREW M6X1X9

93008020060

$2,89

Unit Price

FOOTREST FRONT LEFT CPL. (93003042000, 93003140033)
FOOTREST FRONT LEFT CPL.

90103040033

$24,66

Unit Price

PLAIN WASHER 6, 4X12X1

90103040001

$1,44

Unit Price

CAP SCREW M6X10 SS

J029060103S

$2,89

Unit Price

PIN FOOTREST PIVOT BLACK

93003054000

$2,89

Unit Price

FOOTREST RETURN SPRING

90103042000

$5,80

Unit Price

WASHER M8

J125080004

J125080005

$1,44

Unit Price

PIN 25X1, 8MM

J094018250

$1,44

Unit Price

FOOTREST SUPPORT HOLDER, FRONT

90103038001

$13,98

Unit Price

CHAINGUIDE

90104070000

$15,30

Unit Price

SPACER CHAINGUIDE

90104066010

$4,34

Unit Price

FOOTREST BRACKET REAR LEFT

93003048000

$87,37

Unit Price

O-RING 9X1, 5

J770009015

$1,44

Unit Price

REAR FOOTPEG CMPL. LEFT

90103050033

93003150033

$30,88

Unit Price

PLATE LOCK PILLION STEP BOTTOM

93003053000

$1,44

Unit Price

PLATE LOCK PILLION STEP TOP

93003052000

$1,44

Unit Price

FOOTREST BRACKET REAR RIGHT

93003049000

$93,31

Unit Price

HEXAGON SCREW M6X10

J025060101

$1,44

Unit Price

REAR FOOTPEG CMPL. RIGHT

90103051033

93003151033

$30,88

Unit Price

RETAINING BRACKET

93005084000

$13,98

Unit Price

HH COLLAR SCREW M10X1, 25X265

J025102656

$8,96

Unit Price

HH COLLAR SCREW M10X1, 25X92

J025100926

$4,34

Unit Price

HH COLLAR SCREW M10X110 WS14

J025101103

$4,34

Unit Price

FLANGED NUT M10X1, 25 WS14

90103038002

$2,89

Unit Price

HH COLLAR SCREW M8X105 SW12

J027081053

$2,89

Unit Price

ENGINE BRACE RIGHT

93303006000

$25,73

Unit Price

ENGINE BRACE LEFT250/390

93303005000

$24,94

Unit Price

NUT SOCKET-M10X1.25

93003005100

$2,89

Unit Price

HEEL PROTECTOR RIGHT

93003049050

$4,34

Unit Price

WASHER M8

J125080006

$4,34

Unit Price

REAR FRAME WHITE

9300300200028

$671,60

Unit Price

FOOTREST FRONT RIGHT CPL. (93003042000, 93003141033)
FOOTREST FRONT RIGHT CPL.

90103041033

Contact

FOOTREST BRACKET FRONT RIGHT

93003039000

$253,43

Unit Price

BRACKET SPIDER LH

93003002050

$34,97

Unit Price

BRACKET SPIDER RH

93003002151

$31,80

Unit Price

BRACKET SEAT MOUNT LOOSE

93003002030

$10,42

Unit Price

RETAINING PIN

93007044000

$1,44

Unit Price

SEAT COWL FRONT COMPLETE

93003001070

$5,80

Unit Price

RUBBER BUFFER

93008023000

$1,44

Unit Price

SEAT SUPPORT COMPLETE

93007047033

$7,51

Unit Price

HEXAGON SOCKET SCREW M8X30

J912080303

$1,44

Unit Price

SCREW

93007046050

$9,23

Unit Price

HEXAGON SOCKET SCREWM8X1.25X25

93003002070

$1,44

Unit Price

WASHER PLAIN-ID8.2XOD 14XT 2 BLK
WASHER PLAIN-ID8.2XOD 14XT 2 B

93003002080

Contact

BOLT

90103098000

$2,89

Unit Price

PASSENGER FOOTREST BRACKET

93003056000

$5,80

Unit Price

HEX SOCKET SCREW M6X14

J912060143

$10,28

Unit Price

HEXAGON SOCKET SCREW M8X31

93008019070

$1,44

Unit Price

WASHER PLAIN

J125080002

$1,44

Unit Price

RETAINING BRACKET

93006040060

$5,80

Unit Price

FLAT HEAD SCREW M5X12 PH

J005050123

$1,44

Unit Price

CABLE BRACKET

90111045050

$1,44

Unit Price

FLANGED BOLT M6X14

90103032000

$1,44

Unit Price

RETAINING BRACKET

93013041000

$1,44

Unit Price

HH-COLLAR SCREW M6X10 SW8

J025060109

$1,44

Unit Price

SUPPORT

93013026000

$1,44

Unit Price

ROUNDHEAD SCREW M4X12

J031050121

$1,44

Unit Price

GUIDE CLUTCH CABLE

93032059010

$4,34

Unit Price

CLIP NUT M5

90108050001

$2,89

Unit Price

SCREW M6X1X25

93008043000

$1,44

Unit Price

BOLT M10X135

90203008000

$7,38

Unit Price

WASHER M10

J125100009

$1,44

Unit Price

WASHER - PLAIN

J125140003

$1,44

Unit Price

HEXAGON SCREW M8X25

J912080251

$2,89

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
