HANDLEBAR / CONTROLS

FRAME FOR KTM RC 2016

SIDE / MAIN STAND

Item numbers

FRAME

93503001100

$1 281,53

Unit Price

FOOTREST BRACKET FRONT R/S

90503039000

$96,61

Unit Price

FOOTREST BRACKET FRONT L/S

90503038000

$100,04

Unit Price

FOOTREST FRONT RIGHT CPL. (93003042000, 93003141033)
FOOTREST FRONT RIGHT CPL.

90103041033

Contact

FOOTREST FRONT LEFT CPL. (93003042000, 93003140033)
FOOTREST FRONT LEFT CPL.

90103040033

$24,66

Unit Price

FOOTREST BRACKET REAR R/S

90503049000

$78,40

Unit Price

FOOTREST BRACKET REAR L/S

90503048000

$78,40

Unit Price

FOOTREST SUPPORT HOLDER, FRONT

90103038001

$13,98

Unit Price

CHAINGUIDE

90104070000

$15,30

Unit Price

ENGINE CARRIER R/S

90203006000

$45,26

Unit Price

ENGINE CARRIER L/S

90203005000

$43,28

Unit Price

SPACER CHAINGUIDE

90104066010

$4,34

Unit Price

FLANGED NUT M10X1, 25 WS14

90103038002

$2,89

Unit Price

HH COLLAR SCREW M10X1, 25X92

J025100926

$4,34

Unit Price

HH COLLAR SCREW M10X1, 25X265

J025102656

$8,96

Unit Price

HH COLLAR SCREW M8X105 SW12

J027081053

$2,89

Unit Price

SOCKET HEAD SCREW M8X25 8.8

J912080253

$1,44

Unit Price

CABLE BRACKET

90111045050

$1,44

Unit Price

FLANGED BOLT M6X14

90103032000

$1,44

Unit Price

BOLT FOR FOOTREST

90503045000

$1,44

Unit Price

FOOTREST RETURN SPRING

90103042000

$5,80

Unit Price

O-RING 9X1, 5

J770009015

$1,44

Unit Price

WASHER D=8, 5

90503048010

$2,89

Unit Price

PIN 25X1, 8MM

J094018250

$1,44

Unit Price

BOLT SOCKET M8X1.25XL

90503098000

$1,44

Unit Price

LOCK PLATE LOWER

90503053000

$1,44

Unit Price

LOCK PLATE UPPER

90503052000

$1,44

Unit Price

RUBBER DAMPER FOR FOOTREST

90503050000

$2,89

Unit Price

WASHER M8

J125080005

$1,44

Unit Price

HEAT SHIELD

90805090000

$22,69

Unit Price

REAR FOOTPEG CMPL. RIGHT

90103051033

93003151033

$30,88

Unit Price

REAR FOOTPEG CMPL. LEFT

90103050033

93003150033

$30,88

Unit Price

PLAIN WASHER 6, 4X12X1

90103040001

$1,44

Unit Price

CAP SCREW M6X10 SS

J029060103S

$2,89

Unit Price

ENGINE MOUNTING SCREW M10X132

90103013000

$5,80

Unit Price

BRAKE HOSE GUIDE FRONT

90113025000

$1,44

Unit Price

BRACKET HOSE CLAMP 2

90513046000

$1,44

Unit Price

BRACKET HOSE CLAMP 1

90513045000

$1,44

Unit Price

HH-COLLAR SCREW M6X10 SW8

J025060083

J025060109

$1,44

Unit Price

BRACKET SIDECOVER

90503034000

$5,80

Unit Price

HH COLLAR SCREW M6X10 SW10

J025060103

$1,44

Unit Price

HH COLLAR SCREW M10X110 WS14

J025101103

$4,34

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
