CYLINDER

CRANKSHAFT / PISTON FOR KTM RC 2015

CLUTCH

Item numbers

CRANKSHAFT CPL. (93830018100, J888040150)
CRANKSHAFT CPL.

90230018100

$608,63

Unit Price

GEAR BALANCER DRIVE

90230055000

$43,28

Unit Price

CONICAL WASHER 28, 35X38X1, 75

90230069000

$2,89

Unit Price

NUT FOR DRIVE WHEEL AGW

90130018008

$8,96

Unit Price

ROTOR SCREW CPL.

90239005050

$7,64

Unit Price

PRIMARY GEAR 30T

90232023030

$57,80

Unit Price

SPROCKET CRANKSHAFT

90236014000

$16,88

Unit Price

WASHER PLAIN

90236015000

$2,89

Unit Price

SPECIAL WASHER

90236015001

$1,44

Unit Price

NUT M16X1, 5

90230029000

$7,38

Unit Price

WOODRUFF KEY 4X5X13

J888040050

$2,89

Unit Price

CON ROD CPL. (93830015033, 94330057044)

90230015000

90230015100

$253,68

Unit Price

PARALLEL PIN

90630015002

$2,89

Unit Price

CON ROD SCREW

90230015013

$7,38

Unit Price

CONROD BEARING SHELL

90230015010

$20,32

Unit Price

CONROD BEARING SHELL (GREEN)

90230015011

$20,32

Unit Price

CONROD BEARING SHELL (BLUE)

90230015012

$20,32

Unit Price

PISTON D89

90230007000

90230007200

$437,17

Unit Price

PISTON RINGS CPL.

90230030010

$159,71

Unit Price

RING SNAP

90230074000

$5,80

Unit Price

PISTON PIN

90230033000

$33,52

Unit Price

PLAIN WASHER 28, 2X39X1, 5

90230068000

$1,44

Unit Price

PARALLEL PIN

90134013000

$1,44

Unit Price

PISTON KIT 390 DUKE 2013

90230007010

$446,94

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CRANKSHAFT / PISTON of your KTM RC 390 ADAC CUP of 2015. Let us know if you have any questions.
