GEAR SHIFTING MECHANISM FOR KTM EXC-F 2015

COOLING SYSTEM

Item numbers

SHIFT FORK 5./6.G.

54834201000

$86,71

Unit Price

SHIFT FORK 2./4.G.

54834202000

$87,24

Unit Price

SHIFT FORK 1./3. G.

54834203000

$87,24

Unit Price

NEEDLE ROLLER DIN5402 6X14, 8

0402061480

$5,80

Unit Price

SHIFT SHAFT CMPL.

54834005144

50534005044

$80,77

Unit Price

PRESSURE SPRING 0, 9MM

58038023200

$5,80

Unit Price

SLIDING PLATE

61234008044

$14,77

Unit Price

TENSIONING SPRING 0, 8MM

56534013100

$1,44

Unit Price

SPRING GUIDE

54634020000

$9,10

Unit Price

BALL BEARING 6903 C4

0625069034

$28,76

Unit Price

GEAR SHIFT DRUM

54834212200

$83,94

Unit Price

BALL BEARING 61805 C3

0625618050

$62,03

Unit Price

RETURN SPRING 03

54834014000

$5,80

Unit Price

SHIFT LOCATING DRUM CPL.

77234015000

$66,52

Unit Price

AH SCREW DIN0912-M 6X35

0912060353

$2,89

Unit Price

HEX LOBE COUNTERSUNC SCREW M5X10 - 10.9
HEX LOBE COUNTERSUNC SCREW M5X

0019050106S

$2,89

Unit Price

RETAINING BRACKET CRANKSHAFT BEARING

75030085000

75030085100

$1,44

Unit Price

SHIFT. RAIL MAIN SHAFT 250/300

54834019000

$18,07

Unit Price

SHIFT RAIL COUNTER SHAFT

L54834020000

Contact

ARRESTING LEVER SPRING 03

60034023000

$2,89

Unit Price

LOCATING LEVER CPL. 08

50334024144

$20,58

Unit Price

SLEEVE FOR LOCKING LEVER

54634052300

$4,34

Unit Price

WASHER DIN 9021 A - 5.3

0021050003

$1,44

Unit Price

HH COLLAR SCREW M5X20 TX30

0025050206

$2,89

Unit Price

SHIFT LEVER CPL.RACING 2000

59034031000

$123,80

Unit Price

STEP PLATE FOR SHIFT LEVER 250

54634131000

$44,60

Unit Price

BOLT 6X25 FOR SHIFT LEVER

54634031050

$11,08

Unit Price

SHIFTING LEVER SPRING 250

54634032100

$4,34

Unit Price

STOP DISK 14X30X1

54634050000

$2,89

Unit Price

NEEDLE SLEEVE HK 1412 14X20X12

54632095000

$9,89

Unit Price

RADIAL SHAFT SEAL 14X24X6 B

0760142460

$13,06

Unit Price

STEEL WASHER 6, 4X17X3

50232050001

$7,38

Unit Price

PAIR OF WASHERS M 6 NORDLOCK

50233041000

$5,80

Unit Price

SPECIAL SCREW M6X16 WS=8 10.9

59009062016

$2,89

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the GEAR SHIFTING MECHANISM of your KTM 350 EXC-F of 2015. Let us know if you have any questions.
