HANDLEBAR / CONTROLS

FRAME FOR KTM SX-F 2014

SHOCK ABSORBER

Item numbers

FRAME ANTRAZIT ''777M3''

77703001000BE

$2 125,22

Unit Price

SUB FRAME SX

77203002000

$552,67

Unit Price

SUB FRAME APPLICATION LEFT

78103002010

$31,67

Unit Price

SUB FRAME APPLICATION RIGHT

78103002020

$28,76

Unit Price

REINFORCING

77703013000

$10,42

Unit Price

RUBBER CABLE TIE 75MM 03

60011093075

$7,38

Unit Price

TANK REST RUBBER

77207012000

$13,32

Unit Price

HH COLLAR SCREW M8X16 TX40 SL

0025080166S

$4,34

Unit Price

WIRING HOLDER 16MM

57013072100

$1,44

Unit Price

ENGINE BRAC.SCR. M10X115

77203014000

$12,66

Unit Price

FLAT HEAD SCREW M. ISA45 M8X20

0019080206S

$2,89

Unit Price

HH COLLAR SCREW M8X44 WS13

56530079000S

$4,34

Unit Price

BLIND PLUG-IN NUT M5 WN 22A 03

54803092050

$7,38

Unit Price

CABLE TIE 300/4, 8MM BLACK

44011076305

$2,89

Unit Price

COU.SUNK SCR. AH ISO7380 M5X25

0738050250

$1,19

Unit Price

BUSH F. FRAME PROTECTION 03

54803092060

$5,80

Unit Price

CABLE TIE 140/2, 5MM BLACK

44011076140

$1,44

Unit Price

HEX. NUT DIN EN 1661 M8 WS13
HEX NUT EN 1661 M8 WS13

06923080003

$2,89

Unit Price

SELF LOCKING NUT M10 CU WS=14

54310086100

$2,89

Unit Price

HH COLLAR SCREW M8X30

0025080306

$4,34

Unit Price

WASHER DIN0125-A 6, 4

0125060003

$1,44

Unit Price

HH COLLAR SCREW M6X25 TX30

0025060256

$4,34

Unit Price

FOOTREST L/S 08

78003040050

$61,63

Unit Price

FOOTREST R/S 08

78003041050

$61,63

Unit Price

PIN FOR FOOT PED 51.5X9.8 MM

54803044000

$17,54

Unit Price

FOOTREST SPRING L/S & R/S

54603041000

$7,38

Unit Price

WASHER DIN 125 A 10.5

0125100003

$2,89

Unit Price

PIN DIN 0094-3.2X25 NIRO

0094032253

0094032250

$1,44

Unit Price

FOOTREST L/S + R/S CPL. 09

78003040033

$163,80

Unit Price

ANGLE PIECE '97

50303089000

$7,38

Unit Price

PVC-HOSE 7X10 PER METER

55007016001

$8,57

Unit Price

SPROCKET COVER 350 SX-F

77203096000

$22,03

Unit Price

CHAIN SLIDER LOWER PART CPL.

77203053000

$12,79

Unit Price

BLIND RIVET NUT EM6-60LF/HX

77303139000

$5,80

Unit Price

PLASTIC FRAME PROTECTION SET

77203094000

$73,38

Unit Price

CHAIN SLIDING KIT BELOW CPL.11

77203053010

$26,52

Unit Price

SPROCKET COVER KIT

77203096010

$28,90

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!

Choose your KTM 350 SX-F 2014 model
