GEARBOX MAIN SHAFT

GEARBOX COUNTERSHAFT FOR KTM SX-F 2012

GEAR SHIFTING MECHANISM

Item numbers

COUNTERSHAFT

77233010000

79333010000

$288,67

Unit Price

TAB WASHER BEARING COUNT.SHAFT

78033132000

$7,38

Unit Price

HEX LOBE COUNTERSUNC SCREW M5X10 - 10.9
HEX LOBE COUNTERSUNC SCREW M5X

0019050106S

$2,89

Unit Price

IDLER GEAR 1ST G 28 TEETH

54833011000

79333011000

$224,78

Unit Price

IDLER GEAR 2ND G 26 TEETH

54833012100

54833012300

$218,58

Unit Price

IDLER GEAR 3RD G 24 TEETH

54833013000

79333013000

$188,48

Unit Price

SLIDING GEAR 4 TH.

54833014000

79333014000

$259,37

Unit Price

SLIDING GEAR 5 TH.

54833015000

79333015000

$215,41

Unit Price

RETAINING RING 25X1, 65

77033022000

77033022100

$2,89

Unit Price

SCREW 10.9+SPRING WASHER

59033034044

$11,08

Unit Price

NEEDLE BEAR. K20X24X13

0405202413

$15,30

Unit Price

NEDDLE BEAR. K24X28X11, 9 DIV.

0405242812

$10,28

Unit Price

NEEDLE BEAR. K 22X26X13 TN

0405222613

$12,92

Unit Price

CYLINDRICAL ROLLER BEARING NJ205
CYLINDRICAL ROLLER BEARING NJ2

49030023000

$105,06

Unit Price

BALL BEARING 6203 JR2 C3

0625062035

$20,45

Unit Price

CIRCLIP DIN 0471-17X1, 5

0471170015

$1,44

Unit Price

FRONT SPROCKET 13?TEETH

50033029013

A46033029013

$43,68

Unit Price

FRONT SPROCKET 14?TEETH

50033029014

A46033029014

$43,68

Unit Price

STOP DISC 25, 2X32X1, 5

59033030000

$4,34

Unit Price

STOP DISC 17, 2X30X1

56033030000

$5,80

Unit Price

SPACER BUSHING 12MM

54633014100

$29,56

Unit Price

SHAFT SEAL RING 32X45X7 BSLNBR

0760324571

$7,38

Unit Price

O-RING 25, 12X1, 78 NBR70

0770020220

$4,34

Unit Price

SHIM 20X31.9X1
SHIM 20X32X1

59033080000

$2,89

Unit Price

STOP DISK

50333043000

79333043000

$4,34

Unit Price

COUNTER SHAFT REPAIR KIT

00050000941

78033010010

$73,25

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
