GEARBOX COUNTERSHAFT

KICK STARTER FOR KTM XC-W 2015

GEAR SHIFTING MECHANISM

Item numbers

KICKSTARTER CPL.

77133070144

$182,02

Unit Price

FLAT HEAD SCREW M. ISA45 M8X20

0019080206S

$2,89

Unit Price

WASHER 8MM GALVANIZED

54633037000

$8,57

Unit Price

SHAFT SEAL RING 19X30X7 B

0760193070

$7,91

Unit Price

CIRCLIP DIN0471-17X1

0471170010

$2,89

Unit Price

CIRCLIP DIN0471-19X1, 2

0471190120

$1,44

Unit Price

SPRING HANGER

54633074000

$5,80

Unit Price

NEEDLE BEARING K 22X26X10 A

0405222610

$9,49

Unit Price

BUMP PART

59033069000

$18,73

Unit Price

INTERMEDIATE GEAR 2003

54833024000

Contact

KICKSTARTER SPRING

54633025000

$13,85

Unit Price

DRIVING HUB

54633026000

$2,89

Unit Price

RATCHET GEAR SPRING 1, 2 MM

58033028000

$2,89

Unit Price

STOP DISK 22, 2 X 30 X 1, 5

58033031000

$5,80

Unit Price

SHIM 20X31.9X1
SHIM 20X32X1

59033080000

$2,89

Unit Price

STOP DISK 17, 2X25X1

54633090000

$7,38

Unit Price

SHIM WASHER DIN0988-17X24X0, 5

0988172405

$2,89

Unit Price

KICKSTARTER SHAFT

59033050100

$92,12

Unit Price

KICKSTARTER GEAR 34-T 03

54833051034

$88,96

Unit Price

RATCHET GEAR KICKSTARTER

59033052000

$57,28

Unit Price

HH COLLAR SCREW M6X10 TX30

0025060106

$4,34

Unit Price

HH COLLAR SCREW M6X20 TX30

0025060206

$4,34

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the KICK STARTER of your KTM 300 XC-W of 2015. Let us know if you have any questions.

Select your KTM XC-W model from 2015
